Image preview - the first page of the document
67072-WW-1


>> Download 67072-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of DC Motor
                                                                                                           67072

For Models           6010D, 6012D, 6015D, 6070D, 6071D, 6072D, DA301D, DA3000D, M002, M003,M014
Country              All countries
Description          DC Motor has been changed as shown below.

                       Current                                                     New
                                                                                         3.0 mm
                            2.0 mm                                                        (1/8")
                            (1/16")
                                                                                         2.0 mm
                                                                                         (1/16")

                                  (+)                                                    (+)
                                                                                                            o 16.0 mm
                                        o 16.0 mm (5/8")
                                                                                                                (5/8")
                                  (-)                                                    (-)
                                                                                               o 10.2 mm (13/32")

Interchangeability(I/C)
Item No.     Current part                Q'ty I/C        New part                 Q'ty              Note
         DC Motor                                  DC Motor                              For DA301D, DA3000D.
                                          1     No                                 1
See note 629514-6                                  629801-3                              See note below.
below. DC Motor                                    DC Motor                              For all subject models
                                          1                                        1
         629514-6                                  629801-3                              except DA301D, DA3000D
Interchangeability mark ;
The arrow      means that the new part can be substituted for the current.

Note
Item No. of DC Motor
Model 6010D        6012D     6015D      6070D    6071D     6072D    DA301D     DA3000D         M002     M003   M014
Item No. 005        017       017        005      005       018      010         010           005      005     005
For DA301D, DA3000D only
When installing new DC Motor on DA301D or DA3000D, always remove the ribs of Housings R and L shown below.
                                        Remove these ribs.




             (Housing R only)                                           (Housing R and L)




Implementation
6010D: To be informed later                     DA301D: To be informed later
6012D: Discontinued since May, 2001             DA3000D: Discontinued since Oct., 1993
6015D: To be informed later                     M002: Discontinued since May, 1991
6070D: Discontinued since Jan., 1993            M003: Discontinued since Apr., 1993
6071D: Discontinued since Oct., 2000            M014: Discontinued since May, 1991
6072D: Discontinued since Oct., 1999
