Image preview - the first page of the document
6702D-TE


>> Download 6702D-TE documenatation <<

Text preview - extract from the document
T   ECHNICAL INFORMATION
      Models No.                  6702D
                                                                                                                    New Tool



      Description                 Cordless Angle Screwdriver

CONCEPTION AND MAIN APPLICATIONS
  This tool is ideal for fastening in close quarters as it is           45 mm (1-3/4")                    58 mm (2-1/4")
  a Cordless and Angle type screwdriver.
  It is also idealfor work that requires accurate fastenings as it delivers
  even and consistent torque.
  Model 6702D is sold with a battery cartridge 9100
  but without a fast charger.
  Model 6702DW includes a                                                                                        97 mm (3-13/16")
  battery cartridge 9100 and a fast charger DC9700.

                                                                                   352 mm (13-7/8")



  Specifications
                                                                 DC Magnet Motor 9.6 V
   Fastening Capacities                  Bolt or Nut             3 mm - 6 mm (1/8"- 1/4")
                                         Machine Screw           3 mm -6 mm (1/8"- 1/4")
   Square Drive                                                  9.5 mm (3/8")
   No Load Speed                                                 400 R/min
   Fatening Torque                                               20 kg.cm - 80 kg.cm (1.4 ft.lbs - 5.8 ft.lbs)
   Net Weight                                                    1.4 kg (3.1 lbs)


  Standard equipment
  Battery Cartridge 9100, Fast Charger DC 9700 (6702DW only), Plastic Carrying Case (6702DW only)


  Optional accessories
  Battery Cartridge 9100, Fast Charger DC9700, DC9012, DC9015, Plastic Carrying Case


  Features and benefits
  1. As the tool is turned off automatically and the electric brake stops the motor immediately after the clutch cuts in,
  A) the fastening torque is even and consistent.
  B) no battery energy is wasted.
  C) relatively quiet operation because of no clutch slippage.
  D) there is no torque reduction caused by clutch wear.
  2. Five torque settings: 20 kg.cm (1.4ft.lbs), 35 kg.cm (2.5 ft.lbs)
                           48 kg.cm (3.5ft.lbs), 60 kg.cm (4.3 ft.lbs)
                           80 kg.cm (5.8ft.lbs)
  3. Slim handle for easy gripping
  4. Reversing feature for bolt/nut removal




  The standard equipment for the tools shown may differ form country to country
