Image preview - the first page of the document
6703D-TE


>> Download 6703D-TE documenatation <<

Text preview - extract from the document
T     ECHNICAL INFORMATION

Models No.              6703D
                                                                                                                        New Tool



Description             Cordless Screwdriver

CONCEPTION AND MAIN APPLICATIONS
 Model 6703D is a straight version of the existing
   Model 6702D (Cordless Angle Socket Driver). It is
   equipped with quick-sleeve system for easy                                         45m                   58m
                                                                                          m(1                     m(2
                                                                                              -3/4                   -1/4
   installation/removal of bit.                                                                   ")                     ")




                                                                                                                              97mm(3-13/16")
   This tool is ideal for work which requires accurate,
   uniform-torque fastening of machine screws and nuts.
   Model 6703D is sold with a battery 9100 but
   without a fast charger.
   (Note)
   Model 6703D for some countries and areas is sold without                             333mm(13-1/8")
   a battery cartridge and a fast charger.
   Consult Makita Japan on this matter.

   Main differences between Model 6703D and 6702D are as follows.

                   Model                                     6703D                                    6702D
                  Tool type                            Straight type                                 Angle type
                                           Quick-sleeve system for 6.35 mm
     Bit or socket installation            (1/4") hex shank bit                     9.5 mm(3/8") square drivesystem
                                           Stepless 5 - 37 kg.cm                    Five stages of 20 - 80 kg. cm
     Torque adjust- ment
                                           (0.4 -2.7 ft. lbs)                       (1.4 - 5.8 ft.lbs)


   Specifications
                                                               DC Magnet Motor (9.6 V)
    Capacities                     Nut/Machine Screw           3 mm - 5 mm (1/8" - 3/16")
    Torque                                                     5 kg. cm - 37 kg. cm (0.4 ft. lbs - 2.7 ft.lbs)
    Driving Shank                                              6.35 mm (1/4") Hex
    No Load Speed                                              400 rpm
    Overall Length                                             333 mm (13-1/8")
    Net Weight                                                 1.3 kg (2.9 lbs)

   Standard equipment
   Battery 9100

   Optional accessories
    Phillips Bits, Slotted Bits, Socket Bits, Battery 9100, 9101,
    Fast Charger DC9700, DC9015, DC9112, DC1201, Plastic Carrying Case
   Features and benefits
   1. As the tool is switched off automatically and the electric brake stops
   the motor immediately after the clutch cuts in,
   A) More precise torque can be obtained.
   B) Less waste of battery energy
   C) Relatively quiet operation because of no clutch slippage
   D) No toruqe reduction caused by clutch wear
   2. Refer to the attached sheets for more information.

   The standard equipment for the tools shown may differ form country to country
    Capacity
(1) The fastening torque can be adjusted within the range of 5 kgf-cm-35 kgf-cm in non-step.
     Position of
     torque change ring                     Fastening torque
                1                           5kg. cm(0.4ft. lbs.)
                2                          10kg. cm(0.7ft. lbs.)
                3                          18kg. cm(1.3ft. lbs.)
                4                          27kg. cm(2.0ft.lbs.)
                5                          37kg. cm(2.7ft.lbs.)
    Note) The fastening torque shown on the table above are only for reference.
          Since the fastening torque may vary depending on the type of
          screw and the material of work to be fastened, check the fastening      Working condition
          torque before starting the work.                                                     Small screw : M5 x 14 mm

(2) Working volume per battery(reference values)
About 700 pieces (Position of fastening torque change ring : 5)
                                                                                                    Steel plate with
                                                                                                    13 mm in thickness
Quick-sleeve system : Just pull
out the sleeve and slip the bit in.                                Reversing switch for easy screw/nut removal
Release the sleeve to secure the bit.


                                     Slim body/handle for easy gripping




      9.0




                6.35 (1/4")




                          Stepless adjustment clutch
