Image preview - the first page of the document
67176-WW-1


>> Download 67176-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Change of Spur Gear 13 (a constituent part of Armature)
                                                                                                          67176


For Models             6207D, 6217D, 6237D, 6317D, 6337D, 6347D

Country                All countries

Description            Spur Gear 13 (a constituent part of Armature) has been changed as shown below.
                       Consequently, the part No. for Armature has been changed.

                                       Spur Gear 13




                                                            Armature


                                         Current                                          New
Material                               AISI 12L14H                                     SCM435L
Heat treatment                         Carburizing                                Complete Hardening
Interference of
                                   18 - 36 micron                                    13 - 31 micron
press fitting


Interchangeability(I/C)
Item No.       Current part                    Q'ty I/C          New part                Q'ty           Note
           Armature                             1           Armature                      1
    016                                               Yes                                       For 6207D
           619078-8                                         619117-4
           Armature                                         Armature
    016                                         1     Yes                                 1     For 6217D, 6317D
           619079-6                                         619116-6
           Armature                             1           Armature                      1
    016                                               Yes                                       For 6237D, 6337D
           619080-1                                         619115-8
           Armature                                         Armature
    016                                         1     Yes                                 1     For 6347D
           619082-7                                         619118-2

Implementation
To be informed later
