Image preview - the first page of the document
67107-WW-1


>> Download 67107-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                          Change of Switch, Power Supply Cord, etc.
                                                                                                                                67107
                                                                                                                              (Page 1 of 3)


For Models                       M101, M362, M511, M515, M516, M992, SR1600, SR1800, 1125, 1901, 3608B, 3620, 3621,
                                 4100R, 4103KB, 4101RH, 4105KB, 4200N, 5000SB, 5000SBR, 5011NB, 5012B, 5600BR, 5801B
Country                          See page 2.
Description                      The followings have been implemented to comply with UL or CSA Standards.
                                 1) Change of Switch (For all models above)
                                    The new Switches don't come with four M3.5 Pan Head Screws.
                                 2) Addition of Terminal Block (For M362, 3620, 3621 only)
                                 3) Change of Power Supply Cord, addition of Cord Guard, Strain Relief and Pan Head Screw
                                   (For 3621 only) < molded cord guard      unmolded one >,
                                 Consequently, wirings have been changed.


For Model 3620, 3621, M362
  Change of Switch
                                                Current                                                         New
Manufacturer                                  OMRON                                                     FUJISOKU
Cat. No.                                     C2M-M1T                                                   SGE115CDY-5
Terminal Screws                       (These come with Switch)                                    Pan Head Screws M3.5 x 7
Part No.                                        651236-0                                                  651280-7
  Change of Wiring
                                               Current                                                              New
             Power Supply Cord




                                                                              Power Supply Cord




                                  Switch                                                               Switch
                                  2      1                     To Field                             3           2                To Field
 Wiring                                                    Noise Suppressor                                                  Noise
                                                                                                                             Suppressor
                                  4      3                     To Field                             Terminal
                                                                                                    Block                        To Field

  Noise Suppressor is not used in some countries and areas.

For all Models except 3620, 3621, M362
  Change of Switch
                                                Current                                                         New
Manufacturer                                  OMRON                                                     FUJISOKU
Cat. No.                                     C2M-M1T                                                     SGE215C
Terminal Screws                       (These come with Switch)                                    Pan Head Screws M3.5 x 7
Part No.                                        651236-0                                                  650210-5
  Change of Wiring
                                               Current                                                              New
             Power Supply Cord




                                                                              Power Supply Cord




                                  Switch                                                            Switch
                                  2      1                     To Field                            3       2                  To Field
 Wiring                                                    Noise Suppressor                                               Noise Suppressor
                                  4      3                     To Field                            6       5                  To Field


  Noise Suppressor is not used in some countries and areas.
                                                                                                            67107
                                                                                                          (Page 2 of 3)
 Interchangeability(I/C)
For 3620, 3621, M362
 Item No.        Current part                   Q'ty I/C         New part                    Q'ty         Note
           Switch C2M-M1T                                Switch SGE115CDY-5
    012                                          1    No                                      1
           651236-0                                      651280-7
3620: 705                                                Pan Head Screw M3.5x7                       Interchangeable
3621: D02                                                                                     2
M362: 703                                                652008-6                                         as a set
3620: 707                                                  Terminal Block 1P
3621: D03                                                                                     1
M362: 704                                                  654532-5
For 3621 only
 Item No.        Current part                   Q'ty I/C        New part                     Q'ty         Note
           Power Supply Cord                             Power Supply Cord
    008    AWG#18-2-2.0                          1    No AWG#18-2-2.5                         1
           664424-0                                      664013-1
                                                         Cord Guard 8-85                             Interchangeable
    009                                                                                       1
                                                         682502-4                                      as a set with
                                                           Strain Relief                            Power Supply Cord
    010                                                                                       1
                                                           687001-1
                                                           Pan Head Screw M4x18
    011                                                                                       2
                                                           911133-5
For all Models except 3620, 3621, M362
  Item No.        Current part                  Q'ty I/C           New part                  Q'ty         Note
           Switch C2M-M1T                                  Switch SGE215C
 See below                                       1                                            1
           651236-0                                        650210-5                                  Interchangeable
                                                           Pan Head Screw M3.5x7                          as a set
 See below                                                                                    4
                                                           652008-6
Interchangeability mark ;
 The arrow      means that the current part is substituted for the new.
Item No. of Switch
 Model       M101    M511    M515     M516     M992 SR1600 SR1800         1125     1901    3608B      4100R 4101RH
Item No.     014     007     040       041     006    040    041          011      014      028        054    054

 Model 4103KB 4105KB 4200N 5000SB 5000SBR 5011NB 5012B                         5600BR 5801B
Item No. 004   046    002   009     005    057    034                            011   016
Item No. of Pan Head Screw M3.5 x 7
 Model       M101    M511    M515     M516     M992 SR1600 SR1800         1125     1901    3608B      4100R 4101RH
Item No.     700     700     700       700     700    700    700          706      700      700        700    D01

 Model 4103KB 4105KB 4200N 5000SB 5000SBR 5011NB 5012B                         5600BR 5801B
Item No. 700   704    705   700     700    700    700                            700   700

 Note
Applicable countries
                            Model                                              Countries
               3620                               All countries
               3621                               U.S.A., Mexico, Panama, Guam
 Continued     4101RH                             Australia, New Zealand
 Models        4105KB                             Austria, France, Germany, Italy, Netherlands, Russia, Spain, Sweden,
                                                  U.K., Algeria, Reunion, Turkey, Australia, New Zealand
               4200N                              New Zealand
               5012B                              Tahiti
               M101, M362, M511, M515, M516,
Discontinued M992, SR1600, SR1800, 1125, 1901 Countries where Switch (651236-0) has been used
Models       3608B, 4100R, 4103KB, 5000SB,    as replacement part.
               5000SBR, 5011NB, 5600BR, 5801B
                                            67107
                                           (Page 3 of 3)

Implementation
M101: Discontinued since April, 1992
M362: Discontinued since April, 1993
M511: Discontinued since July, 1992
M515: Discontinued since August, 1991
M516: Discontinued since August, 1991
M992: Discontinued since April, 1993
SR1600: Discontinued since April, 1995
SR1800: Discontinued since April, 1995
1125: Discontinued since April, 1994
1901: Discontinued since May, 1999
3608B: Discontinued since April, 1993
3620: From December, 2002 production
3621: From December, 2002 production
4100R: Discontinued since April, 1993
4103KB: Discontinued since October, 1992
4101RH: From December, 2002 production
4105KB: From December, 2002 production
4200N: From December, 2002 production
5000SB: Discontinued since April, 1989
5000SBR: Discontinued since June, 1991
5011NB: Discontinued since April, 1989
5012B: From December, 2002 production
5600BR: Discontinued since April, 1995
5801B: Discontinued since May, 1995
