Image preview - the first page of the document
67251-WW-1


>> Download 67251-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                  Change of Brush Holder
                                                                                                        67251


For Models               MCC and MKC products: 6409, 6410, 9035, BO3700, BO4510, M926
                         MJ products for Taiwan: 6410, BO3700, M926
Country                  All countries
Description              Material and Manufacturer of Brush Holder have been changed as shown below.

                           Current                             New
    Material          Diallyl Phthalate AM312                Phenolic
                                                     Shanghai European-Asian
 Manufacturer     Sumitomobakelite Co. Ltd
                                                     Synthtic Material Co. Ltd

Interchangeability(I/C)

 Item No.      Current part                     Q'ty I/C         New part                 Q'ty         Note
           Brush Holder                                   Brush Holder
See below.                                       2    Yes                                  2
           643552-4                                       643562-1
Item No. of Brush Holder
  Model        6409     6410 9035        BO3700 BO4510       M926
Item No.       019      019 006           004     001         004

Implementation
6409, 9035, BO4510: To be expected to do around Dec., 2002 production
6410, BO3700: To be expected to do around Jan., 2003 production
M926: To be expected to do around Feb., 2003 production
