Image preview - the first page of the document
67295A-WW-1


>> Download 67295A-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                         Change of Steel Carrying Case
                                                                                                                       67295A


For Models                      HM1302, HM1303, HM1303B, HM1500, HM1500B, 8900N
Country                         All countries
Description                     Steel Carrying Case has been changed as shown below.

                                    Current                                                            New



                                                                                                                         165 mm
                                                             C                                                           (6-1/2")


                                A                                                           755 mm
                                                     B                                     (29-3/4")
                                                                                                                   280 mm
                                                                                                                    (11")
                   Dimensions
           Model    A                        B           C
                 704 mm                   270 mm      160 mm
        HM1302 (27-3/4")                 (10-5/8")   (6-5/16")
        HM1303 773 mm                     270 mm      180 mm
        HM1303B (30-1/2")                (10-5/8")    (7-1/8")
        8900N
                 740 mm                   365 mm 180 mm
        HM1500
                (29-1/8")                (14-3/8") (7-1/8")
        HM1500B



Interchangeability(I/C)
Item No.         Current part                        Q'ty I/C           New part                  Q'ty              Note
           Steel Carrying Case Set                               Steel Carrying Case Set                 For HM1302 for Indonesia,
           183189-0                                      1   Yes 183567-4                          1     Korea, Malaysia, Philippines
  A05
                                                                                                         Singapore, Thailand,
                                                                                                         Vietnam
           Steel Carrying Case Set                               Steel Carrying Case Set                 For HM1302 for Brazil,
           182753-4                                                                                      Chile, Panama,
  A05                                                    1   Yes 183567-4                          1
                                                                                                         Canary Islands,
                                                                                                         Guam, Tahiti
         Steel Carrying Case Set                                 Steel Carrying Case Set
  A02                                                    1   Yes                                   1     For HM1303
         182851-4                                                182851-4
         Steel Carrying Case Set                                 Steel Carrying Case Set
  A02                                                    1   Yes                                   1     For HM1303B
         182852-2                                                182851-4
         Steel Carrying Case Set                                 Steel Carrying Case Set                 For HM1500 for all coun-
See note
         182714-4                                        1   Yes 182714-4                          1     tries except China
below.
                                                                                                         For 8900N
           Steel Carrying Case Set                               Steel Carrying Case Set
  A05                                                    1   Yes                                   1     For HM1500 for China
           182968-3                                              182968-3
           Steel Carrying Case Set                               Steel Carrying Case Set
  A04                                                    1   Yes                                   1     For HM1500B
           182715-2                                              182851-4
Note                                                               Implementation
Item No. of Steel Carrying Case                                    All models on the subject except 8900N: To be informed later
HM1500: A05       8900N: 406                                       8900N: Discontinued since Oct., 1991
