Image preview - the first page of the document
67378-WW-1


>> Download 67378-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Addition of Flat Washer 9 and Modification of Inner Housing Complete
                                                                                                             67378

                       HR2020, HR2021, HR2022, HR2440, HR2441,HR2442, HR2450, HR2451, HR2452, HR2440F
For Models             HR2450F
Country                All countries

Description            1. Flat Washer 9 has been added.
                       2. Inner Housing Complete has been modified so that Flat Washer 9 can be installed.

                         Current                                                       New
                Inner Housing Complete                                        Inner Housing Complete


                                    Ball Bearing 609                                             Ball Bearing 609




                                    Armature                           Flat Washer 9             Armature


Note:
Always put Flat Washer 9 onto Ball Bearing 609 so that the marking on the Flat Washer 9 should face outward.
Remove the burr on the Flat Washer 9 if the above work cause them.

 Marking should face outward.




                       Flat Washer 9


                                                   Ball Bearing 609
 Interchangeability(I/C)
Item No.        Current part                Q'ty I/C              New part                Q'ty              Note
See note                                                   Flat Washer 9
                                                                                           1
below.                                                     267271-4
           Inner Housing Complete                          Inner Housing Complete                For HR2020, HR2021,
           153287-4                                        153611-1                              HR2022, HR2440,
    049                                        1                                           1
                                                                                                 HR2441, HR2442,
                                                                                                 HR2440F
         Inner Housing Complete                       Inner Housing Complete                     For HR2450, HR2451,
    049                                     1                                              1
         153367-6                                     153610-3                                   HR2452, HR2450F
Interchangeability mark ;
The arrow       means that the new part can be substituted for the current.

 Note
  Model HR2020 HR2021 HR2022 HR2440 HR2441 HR2442 HR2450 HR2451 HR2452 HR2440F HR2450F
Item No. 079    079    079    079    079     079   091    091    091     080     092


 Implementation
To be informed later
