67435-WW-1


>> Download 67435-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                  Change of Keyless Drill Chuck S13 and Hex. Socket Head Bolt
                                                                                                             67435


For Models               6313D, 6333D (MCA products only)

Country                  All countries

Description              We postpone implementation on our previous Technical Information No.65531
                         (Change from JACOBS's chuck to ROHM's chuck) for a while.
                         Therefore Keyless Drill Chuck S13 and Hex. Socket Head Bolt are changed in your part list
                         at this time.

                           Current                                                       New
         21mm (13/16")                                                  32 mm (1-1/4")




    Hex. Socket Head Bolt       Keyless Drill Chuck 13 Set     Hex. Socket Head Bolt      Keyless Drill Chuck 13 Set
           M5x21                 (Manufacturer: ROHM)                 M5x32               (Manufacturer: JACOBS)



Interchangeability(I/C)
For all countries except North America
 Item No.           Current part                   Q'ty I/C            New part                   Q'ty        Note
6313D: 015 Keyless Drill Chuck 13 Set                       Keyless Drill Chuck 13 Set
                                                     1   No                                        1
6333D: 017 193695-7                                         192891-4
                                                                                                         Interchangeable
           Hex. Socket Head Bolt                            Hex. Socket Head Bolt
6313D: 016 M5x21                                                                                              as a set
                                                     1   No M5x32                                  1
6333D: 018
           265998-0                                         266154-5

For North America
 Item No.           Current part                   Q'ty I/C            New part                   Q'ty        Note
6313D: 015 Keyless Drill Chuck 13 Set                       Keyless Drill Chuck 13 Set
                                                     1   No                                        1
6333D: 017 193693-1                                         192891-4
                                                                                                         Interchangeable
           Hex. Socket Head Bolt                            Hex. Socket Head Bolt
6313D: 016 M5x21                                                                                              as a set
                                                     1   No M5x32                                  1
6333D: 018
           265998-0                                         266154-5


 Note
 This Technical Information is issued on Oct.,29,2002.
