Image preview - the first page of the document
67436-WW-1


>> Download 67436-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject             Addition of Dust Cover
                                                                                               67436


For Models          DA4511, DA6300, DA6301, DS4000

Country             All countries
Description         Dust Cover has been added to protect Switch from dust.

      Installing Dust Cover




                              Install




                                                              Dust Cover                    (Handle R)
                                                  (Switch)
                                                                             (Switch)
                Dust Cover
                (421297-2)
      1. Attach Dust Cover onto the upper side of Switch.
      2. Install them (Switch with Dust Cover) to Handle R.
      3. Fix Handle L to Handle R.


Interchangeability(I/C)
For DA4511, DS4000
 Item No.       Current part                 Q'ty I/C         New part        Q'ty          Note
DA4511: 020 Handle Set                                  Handle Set
DS4000: 041                                   1    No                          1
        047 181655-1                                    183583-6                        Interchangeable
                                                        Dust Cover                           as a set
DA4511: 064
                                                                               1
DS4000: 048                                             421297-2

For DA6300, DA6301
 Item No.       Current part                 Q'ty I/C         New part        Q'ty          Note
              Handle Set                                Handle Set
  022, 029                                    1    No                          1
              182280-1                                  183584-4                        Interchangeable
                                                        Dust Cover                           as a set
DA6300: 064
                                                                               1
DA6301: 067                                             421297-2


Implementation
DA4511: Discontinued since October, 2000
DA6300, DA6301: To be informed later
DS4000: From initial production
