Image preview - the first page of the document
67670-WW-1


>> Download 67670-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of O Ring
                                                                                              67670


For Models           6830, 6832, 6833, 6834, 6836
Country              All countries
Description          O Ring has bee changed as illustrated below.


                                      Current                        New
                                     O Ring 22.4                   O Ring 24
                                     (213008-7)                    (213380-7)




Interchangeability(I/C)
Item No.      Current part                  Q'ty I/C          New part          Q'ty   Note
See note O Ring 22.4                                    O Ring 24
                                             1                                   1
 below. 213008-7                                        213380-7
Interchangeability mark ;
The arrow      means that the new part can be substituted for the current.

Note
Item No. of O Ring
   Model      6830       6832        6833        6834       6836
 Item No.      050        053         049         048        049


Implementation
6830: Discontinued since May, 2001
6832: Discontinued since May, 2001
6833: To be expected to do around January, 2003
6834: To be expected to do around January, 2003
6836: To be expected to do around January, 2003
