67752-WW-1


>> Download 67752-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Change of Power Supply Cord and Strain Relief
                                                                                                          67752


For Models             HP2050, HP2050F, HP2051, HP2051F
Country                European countries except for Germany, Sweden, Switzerland, U.K.(110V, 240V)
                       Note: This technical information also applies to the models HP2050 and HP2051 for Turkey.
Description            Power Supply Cord and Strain Relief have been changed as shown below.

                                                 Current                                    New
                       Material              Polyvinyl chloride                             Rubber
 Power Supply Cord
                       Diameter                6.7mm(1/4")                              7.0mm(9/32")
                                                 20mm
                                                                                            20mm
                                                (13/16")
                                                                                           (13/16")

  Strain Relief
                                  6mm                                        6mm
                                  (1/4")                          10mm       (1/4")                          8mm
                                                                  (3/8")                                    (5/16")
                                               (687063-9)                                 (687052-4)

Interchangeability(I/C)
Item No.           Current part                 Q'ty I/C            New part                    Q'ty       Note
           Power Supply Cord 1.0-2-2.5                   Power Supply Cord 1.0-2-2.5
  059      HD-21                                 1    No VOLEX                                   1
                                                                                                       Interchangeable
           666066-6                                      665394-6
                                                                                                            as a set
           Strain Relief                                 Strain Relief
  055                                            1    No                                         1
           687063-9                                      687052-4

Implementation
To be informed later
