67874-WW-1


>> Download 67874-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject             Change of Dust Bag etc.
                                                                                                        67874


For Models          BO5010, BO5012

Country             European countries
Description         Dust Bag and the relevant parts have been changed as illustrated below.

                      Current                                                       New
                 Dust Bag                                                 Paper Dust Bag Set
                (166047-5)                                            Standard equipment: 1 pc. only
                                                                 Accessory: Part No. 193712-3 (5 pcs./1 set.)

                         Dust Bag Nozzle
                           (416063-0)


                                   Dust Nozzle
                                   (416064-8)

                                              Ring 25
                                            (257202-1)     Paper Dust Bag Holder
                                                                 (193713-1)




Interchangeability(I/C)
Item No.           Current part                Q'ty I/C           New part                    Q'ty     Note
BO5010: 013   Dust Bag
              166047-5                           1
BO5012: A01
BO5010: 012   Dust Bag Nozzle
              416063-0                           1
BO5012: A03
BO5010: 008   Dust Nozzle
              416064-8                           1
BO5012: A04
BO5010: 009   Ring 25
              257202-1                           1
BO5012: A02
BO5010: A04                                               Paper Dust Bag Set
                                                          193712-3                             1
BO5012: A07
BO5010: A05                                               Paper Dust Bag Holder
                                                          193713-1                             1
BO5012: A08

Implementation
BO5010: From Apr.,2003 production
BO5012: From serial No.2200A (Jan.,2003)
