TECHNICAL INFORMATION
Subject               Addition of Adhesive and Modification of Gear Housing Cover Complete
                                                                                                             67951


For Models            HP2050, HP2050F, HP2051,HP2051F

Country               All countries
Description           See below.

1. Adhesive (Three Bond 1327) has been applied to threaded portion of Bearing retainer.

                                                 Bearing Retainer
                                                 Note: Apply adhesive (Three Bond 1327) to its threaded portion
                                                       when installing it in Gear housing complete.


                                                              Gear housing complete




2. Shape of Gear housing cover complete has been modified as shown below.

                     Current                                                            New

                                                                             This portion of Gear housing cover complete
                                                                             has been cut off for distinction.




 Interchangeability(I/C)
Item No.       Current part                Q'ty I/C            New part                     Q'ty           Note
                                                        Three Bond 1327 (50g)
                                                                                            0.1g
                                                        045032-0A
           Gear Housing Cover                           Gear Housing Cover
    024    Complete                          1          Complete                             1
           153364-2                                     153620-0
Interchangeability mark ;
The arrow      means that the new part can be substituted for the current.

 Implementation
From Mar., 2003 production.
