Image preview - the first page of the document
6795D-TE


>> Download 6795D-TE documenatation <<

Text preview - extract from the document
T       ECHNICAL INFORMATION

                               6795D
                                                                                     New Tool

         For Models
         Description           Cordless Screwdriver


CONCEPTION AND MAIN APPLICATIONS
Model 6795D is the sister version of the existing
Model 6791D, 6793D(Fastening torque=20~120kgf/cm )
and Model 6792D, 6794D(Fastening torque=20~80kgf/cm ).
Its brief benefits are;




                                                                               (8-7/8")
                                                                               225mm
                                                                  58mm
*Fastening torque(5~35kgf/cm) is suitable                        (2-1/4")
  for fastening machine screws.
*The motor stops automatically quickly
  after declutching by electric brake
  to prevent impact of declutching.
*Control circuit cuts off the current automatically
  when battery voltage decrease to a certain level                     178mm
                                                                        (7")
  to prevent fastening with less torque than required.
*Equipped with electric brake


    Specifications
       Motor                   DC 9.6V magnet motor
       No load speed           1700rpm
       Bit tpye                Hex. shank bit
                               Width across flats:6.35mm(1/4")
       Fastening torque        Approx.5~35kgf/cm
                                      (4~30inch/lbs)
                                      (0.5~3.4N/m)
       Net weight              1.5kg(3.21bs)
                               (Including battery)



    Optional    accesories
    Battery 9100
    High Capacity Battery 9102, 9122, 9102A
    Fast Charger DC9700, DC1290, DC1201, DC1410, DC1209
    Fast Automotive Charger DC1412


    Featured    and benifits
    See the sheets attached for more information.
                                                       The motor stops automatically
                                                       quickly after declutching
                                                       by electric brake.
                                                       Impact of declutching can be prevented.


Less torque
                                                       Control circuit cuts off
Approx. 5~35kgf/cm                                     the current automatically
      (4~30inch/lbs)                                   when battery voltage decrease
                                                       to a certain level.
                                                       Fastening with less torque than required
                                                       can be prevented.




        Function of control circuit

              High                Available     Unavailable




                                                Set up value
          Battery                                              If Battery voltage becomes under the setup value,
          voltage                                              the current is stopped.




              Low

                        Big                   Small
Efficiency
1. Fastening torque

  Dial No.                                         2           3          4            5        6          8          10        12
  Fastening torque (kgf/cm)                       5.0         13.0       17.0         19.0     22.0       27.0       30.0      35.0


2. Number of driving screws from a single charge (With Battery 9100)

    Size of screw                Number of driving screws
       M3 X 6                         Approx. 650
       M4 X 8                         Approx. 650
      M5 X 10                         Approx. 650


Circuit   diagram

                                                         Switch
                                           Red
                                                  NC
                       Red
              T+                                  NC       COM
                       White                                            Back/Forth Switch
                                                                             1    4
               Battery holder                    Black
                                                                             2    5

              T-                                                             3               Red
                      Black                      Brown            Red                              M+    Red mark
                               Control circuit
                                                                                                        Direct current motor
                                                                                  Black
                                                                                                   M-
Repair
Same way as in 6793D and 6794D
