Image preview - the first page of the document
6791D-TE


>> Download 6791D-TE documenatation <<

Text preview - extract from the document
T   ECHNICAL INFORMATION
     Models No.              6791D
                                                                                                       New Tool


     Description             MAKITA Cordless Screw Driver

CONCEPTION AND MAIN APPLICATIONS                                                              56

  Makita Cordless Screw Driver provides high efficiency
  function. The driver is stopped by clutch action when screw is
  tightened and at the same time switch is turned off the electric
  circuit automatically and brake is applied to stop motor rotation.
  Then the driver provides small variation in its tightening torque                           158         221
  availing battery energy effectively without eliminating energy
  loss. We also have developed new type battery [DC9000 and
  DC9100 battery charger are used.] to obtain improved machine
  balance.
  Model 6791D is battery mounted type without charger. Model
  6791DW is battery mounted type with charger.                                            183




  Specifications
   DC magnet motor
   No load speed (R.P.M.)                400/min
   Driver bit                            6.35 mm hex bit
   Function                              Variable torque adusting
                                         Tightening torque value [Minimum 20 kg-cm ~ Maximum 100 kg-cm]




  Standard equipment
   Phillips bit 2-45, 3-45


  Optional accessories
  Phillips bit 2-45, 2-65, 2-82, 2-110, 2-150, 2-250, 3-45, 3-65, 3-110
  Minus bit 5-4.5, 5-82, 6-70, 6.35-45, 8-45, 8-70, 10-52, 10-70, 10-52
  Socket bit 7-55, 8-55, 10-55, Makita battery 9100, 12V rapid charger [DC9012] for vehicle


  Features and benefits
   (1) Following features and benefits can be obtained because switch circuit is automatically
             interrupted at the same time clutch is activated.
     1. Variation of tightening torque is small and high accuracy is obtained.
    2. Battery energy is effectively used because useless hitting of clutch is eliminated.
    3. Quiet operation is maintained because hitting sound of clutch is reduced as short as possible.
    4. Durability of clutch is excellent and tightening torque is stabled.
   (2) Following features and benefits can be obtained by adoption of new type battery.
    1. Machine balance is improved.
    2. Easy to grip because gripping of around switch portion of handle becomes slim.
   (3) Continuous operation can be effectively performed because motor brake makes motor rotation stop immediately.
   (4) Wide range of tightening torque can be changed in step-less.

  The standard equipment for the tools shown may differ form country to country
Capacity
1. Tightening torque for screw
(1) Numerical numbers 2, 3, 4,
