Image preview - the first page of the document
67924-WW-1


>> Download 67924-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Base, etc.
                                                                                                           67924


For Models            2414B, 2414NB

Country               European countries, Turkey
Description           The following changes have been implemented as described below to comply with CE requirement.


                                                                 New
                                    The current Stopper plate          The current Screw M6x10
                                    (Part No. 344089-1) has            (Part No. 251887-5) has
                                    been eliminated.                   been eliminated.


                                                                                  Hex. socket head bolt M6x10
                                                                                  (Part No. 265985-9)
                                                                                  has been added.
  (Arm: The part remains the same.)                       Wing bolt M6x10
                                                          (Part No. 924306-1)
                                                          has been added.
        Height




  The height of Bases                                                             Under cover (Part No. 345292-7)
  (Part Nos. for 2414B: 165361-6,                                                 has been added.
  for 2414NB: 165341-2) has become
  taller than the current ones.


Interchangeability(I/C)
    Item No.         Current part                 Q'ty I/C             New part                 Q'ty       Note
                 Base                                      Base
      083                                          1    No                                       1     2414B
                 165064-2                                  165361-6
                 Base                                      Base
      079                                          1    No                                       1     2414NB
                 165230-1                                  165341-2
2414B: E11                                                 Under Cover
                                                                                                 1
2414NB: E09                                                345292-7
2414B: E12                                                   Hex. Socket Head Bolt M6                  Interchangeable
                                                                                                 1
2414NB: E10                                                  265985-9                                       as a set
2414B: E13                                                      Wing Bolt M6x10
                                                                                                 1
2414NB: E11                                                     924306-1
2414B: 066 Stopper Plate
                                                   1
2414NB: 053 344089-1
2414B: 067 Screw M6x10
                                                   1
2414NB: 054 251887-5


Implementation
2414B: To be implemented from Apr., 2003 production.
2414NB: To be implemented from Mar., 2003 production.
