TECHNICAL INFORMATION
Subject              Modification of Switch Lever
                                                                                                             68182A


For Models           5007F, 5007FA, 900, 910, 9514B, 9514BH, M954, N9514B
Country              All countries
Description          Switch lever has been modified as illustrated below.
                     Consequently Switch has also been changed.


                        Current                                                          New
                     (Switch lever)                                                      (Switch lever)




                                                                   The shape of the switch lever has been changed
          The switch lever tends to get stuck by dust.
                                                                   for improvement.



Interchangeability(I/C)
Item No.     Current part                 Q'ty I/C              New part               Q'ty               Note
   See Switch SLE 6A                                     Switch SLE 6A
                                           1                                            1
  below. 651514-8                                        651514-8
Interchangeability mark ;
The arrow      means that the new part can be substituted for the current.
Item No. of Switch
     Model       5007F     5007FA              900              910         9514B       9514BH            M954
   Item No.            068                               024                              013


Note
The wiring, assembling and Part No. remain the same.

Implementation
MKC plant
5007F: From serial No. 43401Y (Around June, 2003)
5007FA: From serial No. 4321Y (Around July, 2003)
MCA plant
N9514B: Since around July 2003 production
MJ plant
9514B, 9514BH: Since around July 2003 production




900, 910: Discontinued since May 1999
M954: Discontinued since April 1993
