Image preview - the first page of the document
68117-WW-1


>> Download 68117-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                 Change of Blade Clamping System and Shoe
                                                                                                                 68117
                                                                                                               (Page 1 of 2)


For Models              JR140D, JR180D
Country                 All countries
Description             See below.

1) The following changes have been implemented to make the tool-less blade change system more durable.
                                                       Current
           Clamp                Spring Washer 5        Torx. Socket Head
           (310138-6)           (267758-6)             Shoulder Bolt M5x10               Push Button
                                                       (266272-9)                        162215-8

           Pin 5.5-6                                                                     Compression Spring 16
           (256454-1)                                                                    (233247-3)

          Steel Ball 4.8                                                                 Ring 13
          (216002-8)                                                                     (257226-7)
                                  Compression Spring 3                                                 Slider
          Push Pin                    (233018-8)                                                       (168328-3)
          (323916-5)




                                                           New
          Retaining Ring (EXT)          Compression Spring 6          Shoulder Pin 5
          S-18                              (233345-3)                (256471-1)
          (961078-7)
                                                                                                    Sleeve
                                                               Driving Sleeve Guide                 (310129-7)
                                                               (417791-0)
          Driving Sleeve
          (162228-9)                                                                   Push Plate
                                                                                       (345214-7)
          Pin 3
                                                                                                    Compression Spring 2
          (268094-3)
                                                                                                    (233025-1)

                                                                                                    Torsion Spring 17
                     Guide Sleeve                Pin 3                                              (231662-5)
                     (331639-1)               (256158-5)
                                                                                                            Slider
                                                                                                            (168376-2)




2) Shoe has been changed as shown below.
                                                        Current                                               New
 For European countries
                                                    Shoe (168337-2)                                     Shoe (163441-2)
 except U.K.
                                                       Hex Lock Nut M5-8
                                                           (252103-8)

                            Shoe Plate
                                                                          Spring Washer 5
 For the other countries    (344801-9)
                                                                          (942101-7)

                                                                               Shoe Supporter               Shoe
                            Hex Socket Head Bolt                               (344925-1)                (163442-0)
                            (266241-0)
                                                                                                    68117
                                                                                                  (Page 2 of 2)
Item No.            Current part              Q'ty I/C       New part                Q'ty         Note
  014      Slider                              1   No Slider                          1
           168328-3                                   168376-2
           Ring 13                             1
  011
           257226-7
           Compression Spring 16
  010                                          1
           233247-3
           Compression Spring 3
  009                                          1
           233018-8
           Push Pin
  008                                          1
           323916-5
           Push Button
  007                                          1
           162215-8
  004      Pin 5.5-6                           1
           256454-1
           Steel Ball 4.8
  003      216002-8                            1
           Torx. S. H. Shoulder Bolt M5x10
  006                                          1
           266272-9
           Spring Washer 5
  082                                          1
           267758-6
           Clamp
  005                                          1
           310138-6
                                                         Guide Sleeve
  088                                                                                 1
                                                         331639-1
                                                         Sleeve
  091                                                    310129-7                     1
                                                         Pin 3
  090                                                                                 1      Interchangeable
                                                         256158-5
                                                         Driving Sleeve Guide                     as a set
  089                                                                                 1
                                                         417791-0
                                                         Push Plate
  092                                                                                 1
                                                         345214-7
                                                         Driving Sleeve
  086                                                                                 1
                                                         162228-9
                                                         Pin 3
  087                                                                                 1
                                                         268094-3
                                                         Shoulder Pin 5
  083                                                    256471-1                     1
                                                         Retaining Ring (EXT) S-18
  085                                                                                 1
                                                      961078-7
                                                      Compression Spring 6
  084                                                                                 1
                                                      233345-3
                                                      Compression Spring 2
  093                                                                                 1
                                                      233025-1
                                                      Torsion Spring 17
  094                                                                                 1
                                                      231662-5
           Shoe                                       Shoe                                  For Europe
  017                                          1   No                                 1
           168337-2                                   163441-2                              except U. K.
           Shoe Plate                                 Shoe
  017                                          1   No                                 1
           344801-9                                   163442-0
           Shoe Supporter
  022                                          1
           344925-1
           Hex. Socket Head Bolt M5x50                                                      For the other
  021                                          1
           266241-0                                                                         countries.
           Hex. Lock Nut M5-8
  019                                          1
           252103-8
           Spring Washer 5
  078                                          1
           942101-7

Implementation
To be implemented from May,2003 production.
