Image preview - the first page of the document
68122-WW-1


>> Download 68122-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Base and Chain
                                                                                                                 68122

For Models            2414B, 2414DB, 2414NB, 2416S, LC1200, LC1210, LC1230
Country               All countries
Description        Regarding portable cut-offs 2414B, 2414DB, and 2414NB for Canada, U.S.A.,Mexico and Panama;
                   1) Base and Chain have been changed.
                   2) M6x16 Hex. socket head bolt has been added.
                   Also, Chain of metal cutting saws LC1200, LC1210 and LC1230 has been changed.
                   Regarding all countries except for Canada, U.S.A., Mexico, and Panama, only Chain has been
                   changed.
                   See illustration below for the details.
Canada, U.S.A., Mexico, and Panama
                        Current                                                          New
                                     Base                                                            Base
                       (for 2414DB, 2414NB: 165230-1                                   (for 2414DB, 2414NB: 165354-3
                             for 2414B: 165307-2)                                            for 2414B: 165355-1)




                                                                                           M6x16 Hex. socket head bolt
                                    Chain                     Chain
                                                                                           for 2414B, 2414DB, 2414NB
                                  (282010-1)                (282016-9)
                                                                                                   (922323-5)


All countries except for Canada, U.S.A., Mexico, and Panama
                        Current                                                          New
                                       Chain                                                            Chain
                                    (282010-1)                                                       (282016-9)
                             It consists of eight rings.                                       It consists of ten rings.


Interchangeability(I/C)
Canada, U.S.A., Mexico, and Panama
     Item No.         Current part                 Q'ty I/C        New part              Q'ty                 Note
                   Base                                        Base
        079                                         1                                      1        For 2414DB, 2414NB
                   165230-1                                    165354-3
                   Base                                        Base
        083                                         1                                      1               For 2414B
                   165307-2                                    165355-1
                                                               Hex. Socket Head
2414B, 2414DB: 087                                                                                   For 2414B, 2414DB,
                                                               Bolt M6x16                  1
   2414NB: 088                                                                                           2414NB
                                                               922323-5
                      Chain                                    Chain                             For 2414B, 2414DB, 2414NB,
      See below.                                    1                                     1 2416S, LC1200, LC1210,
                      282010-1                                 282016-9
                                                                                                 LC1230
All countries except for Canada, U.S.A., Mexico, and Panama
 Item No.       Current part              Q'ty I/C        New part                       Q'ty               Note
           Chain                                           Chain                                 For 2414B, 2414DB, 2414NB,
See below.                                     1                                          1      2416S, LC1200, LC1210,
           282010-1                                        282016-9
                                                                                                 LC1230
Interchangeability mark ;
The arrow       means that the new part is substituted for the current.
Item No. of Chain
   2414B 2414DB 2414NB            2416S LC1200 LC1210 LC1230
    084      058        055        095               027              028

 Implementation
2414B, 2414DB, 2414NB: From Jul., 2003 production.                    LC1200: Discontinued since May, 1995.
2416S, LC1230: As soon as the current parts run out.                  LC1210: Discontinued since Jan., 2001.
