TECHNICAL INFORMATION
Subject              Addition of Wave Washer 6
                                                                                            68255


For Models           2414B, 2414DB, 2414NB

Country              All countries
Description          Wave Washer 6 has been added as illustrated below.

                       Current                                                New
 Safety cover


  Center cap
      or
 Safety guide



 + flat head
 screw M6



                                                                            Wave Washer 6
                                                                             (253903-9)


Interchangeability(I/C)

      Item No.           Current part            Q'ty I/C        New part          Q'ty     Note
2414B, 2414DB: 086                                          Wave Washer 6
                                                                                    1
2414NB: 087                                                 253903-9

Implementation
2414DB and 2414NB at MCC: To be implemented from May, 2003 production.
2414B and 2414NB at MJ: To be implemented from Mar., 2003 production.
