Image preview - the first page of the document
6826N-TE


>> Download 6826N-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION
    Models No.               6826N
                                                                                                                  PRODUCT
                                                                                                                    P1/6

    Description              Screwdriver                                         CH                 L

CONCEPTION AND MAIN APPLICATIONS
   The above model is equipped with normal clutch,
   considering facilities for removing screws.                                        H
   (No need to remove locator.)                                                                 W
                                                                                                6826

                                                                                    Dimensions : mm ( " )
                                                                                 Length (L)        282 (11-1/8)
                                                                                 Height (H)        218 (8-5/8)
                                                                                 Width (W)          70 (2-3/4)
                                                                                 Center height (CH) 22.0 (7/8)



 Specification
                                                 Continuous Rating (W)
    Voltage (V) Current (A) Cycle (Hz)                                 Max. Output(W)
                                                  Input     Output
       120            6.5           50/60         (710)       340           590

   No load speed (min-1=rpm)                         0 - 2,500
   Driving shank : mm ( " )                          6.35 (1/4) Hex

                                          Self drilling screw 6mm (1/4")
   Max. driving capacity
                                          Hex screw 6mm (1/4")

   Fastening torque adjustment                           No
   Driving depth adjustment                              Yes
   Reverse switch                                        Yes
   Retractable belt clip                                 Yes
   Soft-grip handle                                      Yes
   Protection from electric shock            by double insulation
   Cord length : m (ft)                              2.5 (8.2)
   Weight : Kg (lbs)                                    1.5 (3.3)



 Standard equipment
    * Magnetic Socket Bit 5/16" - 65 ........................ 1 pc.
   < Note > The standard equipment for the tool shown may differ from country to country.



 Optional      accessories
   * Locator assembly ; 1/4"                   * Magnetic socket bit 1/4"-65                * Philips bit 1-25
   * Locator assembly 5/16"                    * Magnetic socket bit 5/16"-65               * Philips bit 2-25,
   * Locator assembly 3/8"                     * Magnetic socket bit 7/16"- 65              * Philips bit 3-25
   * Locator assembly 7/16"                    * Magnetic socket bit 3/8"-65
   * Locator 7/16" for philips bit             * Magnetic socket bit 10-65
   * Magnetic bit holder 6.35-60               * Socket bit 7/16"-65,
   * Bit holder 6.35-60                        * Socket bit 8-65
Features            and benefits                                                                                     P2/ 6

                                                                 Slim but Powerful 570W Motor
  Equipped with locator and clutch
  for the heavy duty work with socket bit                                         Belt Clip is Retractable into
                                                                                  Body.

                                                                                                In-Line Designed Handle
                                                                                                for better work efficiency
                                                                                                Ergonomic Soft Grip
   Normal clutch,                                                                               Handle.
   considering facilities
   for removing screws
 Possible to remove the screws
 without detaching locator.
                                 Solid Aluminum                                              Durable Cord Guard against
                                 Gear Housing                                                Frequent Inflection

                                                                                   Large Switch with Reversing
                                         Air Outlet Designed for
                                                                                   Lever and Lock-Off Button
                                           Operator's Comfort
                                        Cooling air is exhausted towards the      Convenient for single-handed operation.
                                        bit side for comfortable operation.

Comparison              of products
                             Model No.                                MAKITA                        Competitor A
    Specifications                                6826N               6826           6802BV             Model A
  Power input : W                                   570                 570           510
  Rated amperage with 120V                           6.5                6.5            4.8                6.5
  No load speed (min-1=rpm)                       0 - 2,500          0 - 2,500      0 - 2,500          0 - 2,500
  Max. driving           Self drilling screw    6mm (1/4")          6mm (1/4")     6mm (1/4")         6mm (1/4")
  capacity               Hex screw              6mm (1/4")         6mm (1/4")     6mm (1/4")          6mm (1/4")

  Max. torque when the pressure
                                                  17.2 N.m           17.2 N.m       12.7 N.m           15.4 N.m
  of 150N is loaded to the machine

  Silent clutch                                       No                 Yes            No                 No
  Adjustment of driving depth                         Yes                Yes            Yes                Yes
  Type of Retractable into the body
  belt clip Fixed on the body                                                                              No

  Soft grip                                           Yes                Yes            No                 Yes
  Protection from                                by double          by double      by double           by double
  electric shock                                  insulation         insulation     insulation          insulation
  Cord length : m (ft)                            2.5 (8.2)          2.5 (8.2)      2.5 (8.2)          2.4 (7.9)
               Center height : mm (")           22.0 (7/8)          22.0 (7/8)     29.5 (1-3/16)       25.6 (1)
  Dimensions




               Length : mm (")                 282 (11-1/8)        282 (11-1/8)   265 (10-1/2)        293 (11-1/2)
               Width : mm (")                   70 (2-3/4)          70 (2-3/4)     73 (2-7/8)          65 (2-9/16)
               Height : mm (")                 218 (8-5/8)        218 (8-5/8)     199 (7-7/8)         176 (6-15/16)
  Net weight ; Kg (lbs)                           1.5 (3.3)          1.5 (3.3)      1.7 (3.7)           1.6 (3.5)
Repair                                                                                                            P3/6
< 1 > Lubrication
     Apply MAKITA grease N. No.1 to the following portions marked with black triangle to protect
     parts and product from unusual abrasion. See Fig. 1, Fig. 1A and Fig. 1B.
                                                               16
                               7       11       12       13




                                                               14
                                                Fig. 1                 Gear housing cover

                                       Apply grease
                                       these portions.                          Spur gear 36
     Spindle

                                                                                   Gear complete17-35

                                      Do not apply to the
                                      space for armature
                                      gear.
                                                              After mounting spur gear 36
             After mounting spindle                           and gear complete17-35
                        Fig. 1A                                Fig. 1B

    Item No.        Descriptions                   The portion to be lubricated
       7           Gear housing             See Fig. 1A and Fig. 1B
                                            The clutch portion where spur gear 36 contacts.
     11            Spindle                  The surface where gear housing contacts.
     12            Compression spring 6     Its whole portion
     13            Collared pin 8           Its whole portion
     14            Spur gear 36             Its teeth portion
     16            Gear complete 17-35      Its teeth portion

< 2 > Removing armature
 (1) Remove handle cover by unscrewing 3 pcs. of taping screws 4x25. and the take off carbon brushes. see Fig. 2.
 (2) Unscrew 3 pcs. of tapping screws 4x30 and separate gear housing from motor housing. See Fig. 3.
 (3) Remove gear housing cover from motor housing. Then, armature can be removed together with it. See Fig. 4.


            Tapping screws                                                              Gear housing cover
                 4x30
                                                                                                Armature




                                             Gear housing



          Carbon brush




          Fig. 2                                              Fig. 3                                     Fig. 4
                      Handle cover

                                        Taping screws
                                            4x25
Repair                                                                                                                P4/6
< 3 > Mounting armature
     Take the reverse step of Fig. 2. Fig. 3 and Fig.4.at page 3.

< 4 > Replacing ball bearing 608DDW of armature
   ( 1 ) Remove ball bearing 608DDW with No.1R269 "Bearing extractor" See Fig. 5.
   ( 2 ) Remove flat washer 8. See Fig. 6.




                                                       Ball bearing                                 Flat washer 8
                                                       608DDW
                             Fig. 5                                                Fig. 6

   ( 3 ) Do not forget to mount flat washer 8. See Fig. 6.
   ( 4 ) Mount new ball bearing 608DDW. See Fig. 5.

< 5 > Disassembling spindle section
   ( 1 ) Remove locator and lock ring. Separate gear housing from motor housing. See Fig. 7

                                         Locator     Lock ring      Gear housing




         Tapping screws
              4x30

                                                              Motor housing
                                            Fig. 7


   ( 2 ) Remove the parts from the gear housing in the order of Fig. 8, Fig. 9 and Fig. 10.                 Collared pin 8
                                                      Washer 824       Washer 821                                   Spur gear 36



                        Flat washer 8                  Thrust needle                                        Compression
              Gear complete 17-35                      gauge 821                                            spring 6

         Fig. 8                                      Fig. 9                                         Fig. 10

   ( 3 ) Remove spindle by pushing it from locator side. See Fig. 11. And remove ring 20. See Fig. 12.




                                                                                                  Ring 20
                              Fig. 11                                                   Fig. 12
Repair                                                                                                             P5/6

< 6 > Assembling spindle section
  ( 1 ) Mount ring 20 to spindle as illustrated in Fig. 13. And insert compression spring 6 into the hole of spindle.
       See Fig. 14. Insert collared pin 8 into the hole of spindle. See Fig. 15.

     Ring 20                         Spindle                          Compression
                      Grooved                                         spring 6                        Collared pin 8
                      side




                           Fig. 13                                    Fig. 14                           Fig. 15
          < Note > When mounting ring 20 to spindle, its grooved side has to be faced to the brim portion
                   of spindle as illustrated in Fig. 13.

  ( 2 ) Mount the above spindle to gear housing. See Fig. 16.
  ( 3 ) Mount spur gear 36 to collared pin 8. And then, mount the parts in the order of washer 824 (thick one),
       thrust needle gauge 821 and washer 821 (thin one), to the collared pin 8. See Fig. 17.
  ( 4 ) Mount flat washer 8 to gear complete 17-35. Mount this gear complete 17-35 to gear housing. See Fig. 18.
  ( 5 ) Mount the assembled spindle section (gear section) to motor housing as illustrated in Fig. 7 at page 4.

                                                Washer 824
                                                (thick)          Washer 821
               Spindle                                           (thin)               Gear complete 17-35
                                 Spur gear 36
                                                                                               Flat washer 8



                                                          Thrust needle
                                                          gauge 821
            Fig. 16                        Fig. 17                                            Fig. 18


< 7 > When replacing carbon brush, be sure if brush holder is installed on motor housing properly.
      And then install handle cover onto motor housing.
      (see Fig. 19.)

        < Properly installed carbon brush>
                                                                  Correct with your finger to install
                                                                  properly.

          Brush holder

                                      Carbon brush




                                               Motor housing



                                                      Fig. .19
Circuit    diagram                                                                                                      P6/6
                                               Brush holder                                       Brush holder

      Color index of lead wires
    Black
    White
    Red
    Blue


                                                                   2   M1                     4
                                                                   1                         3
                                                                            Switch
                                                                   1   2      M2      C1     C2


                                                                                     Noise
                                                                                     suppressor


                                               Power supply cord



Wiring      diagram


   Hold the connecting lead wire
                                                                                     Hold the connecting lead wire
   (black) between field and switch,
                                                                                     (black) of field, with the lead holder
   with the lead holder as illustrated.
                                                                                     as illustrated.

                                                                                     Hold the following lead wires
                                                                                     with the lead holder as illustrated.
          Hold the brush holder's
                                                                                     * Connecting lead wire (black) of field
          lead wire (red) with the
                                                                                     * Brush holder's lead wire (blue)
          brush holder as illustrated.


                                                                                     Hold the following lead wires
           Put the slack portions of                                                 with the lead holder as illustrated.
           lead wires in this area.                                                  * Connecting lead wire (black) of field
                                                                                     * Connecting lead wire (white) between
                                                                                       field and switch




                                                                                       Pay attention, not to pinch the
                                                                                       lead wires with the rib for terminal
                                                                                       block holding.
           Put noise suppressor into the
           illustrated space, if it is used.
