Image preview - the first page of the document
6821-TE


>> Download 6821-TE documenatation <<

Text preview - extract from the document
T      ECHNICAL INFORMATION
        Models No.                  6821
                                                                                                                        New Tool


        Description                 Drywall Screwdriver

CONCEPTION AND MAIN APPLICATIONS                                                              273mm (10 3/4")
Model 6821 is a low-cost version that has been succeeding model
#6820V with clam shell housing. The functions of variable speed




                                                                                                                            197mm (7 3/4")
and reversing were combine as one switch. It's shape of the grip
is designed for operator to be able to push the center of the drill
shaft effectively and large trigger switch improves operability.




                                                                                         68
                                                                                              m
                                                                                              m
                                                                                                  (2
                                                                                                   11
                                                                                                       /1
                                                                                                       6"
    Specifications




                                                                                                            )
                                                                    Continuous Rating (W)                         Max.
      Voltage (V)        Current (A)           Cycle (Hz)           Input           Output                      Output(W)
          100                 6.0                 50/60              570             280                           590
          120                 5.2                 50/60              570             280                           590
          200                 3.0                 50/60              570             280                           590
          220                 2.7                 50/60              570             280                           590
          230                 2.6                 50/60              570             280                           590
          240                 2.5                 50/60              570             280                           590

      No load speed                         0-4000/min
      Driving shank                         Phillips bit 2-25, Magnetic connect bit 6.35-60
                                            [opposite side 6.35mm (1/4" ) hexagonal]
      Max. capacity     Drywall             5mm, No10 (0.190")
                        Teks                6mm, No14 (0.242")


    Standard equipment
       Phillips bit 2-25 ---------------------------------------1
       Magnetic connect bit 6.35-60 ----------------------1
       Phillips bit 1-25, Phillips bit 2-25,
       Phillips bit 3-25,
       Magnetic connect bit 6.35?60
                                 Adjustment of driving depth is
                                 easy and speedy with a notch
                                 type adjuster ring.



Adjustment sleeve can be attached /                                  Air blow openings prevent   Hook united in the housing
detached easily and it is convenient                                 powdered dust from
for tightening of teks screw.                                        spattering over operator.
It can be removed together with lock
cylinder.


                                                                                                 Center of the shaft can be
                                                                                                 just aimed and pushed by
                                                                                                 linear structure.




     Bit does not rotate               Built-in reversing switch and variable
Rubber ring has improved               speed switch that has a large trigger
the dust-proof capacity and it
prevents the bit from rotating


                                                              Low noise
                                                     Makita 6821           78dB
Repair
For disassembly and assembly pay following attentions.


                                                                                                     Thrust needle bearing 821
                                                      Oil-less bearing 14




                                                             Spindle        Ring 20

                                                     Large view                       Collar pin 8            Helical gear 46




1)   Mount ring 20 so that it's tapered side contacts spindle.
2)   Mount collar pin 20 so that it's width across flat faces spindle.
3)   Mount thrust needle bearing 821 so that washer that has a bigger outer diameter should be on helical gear 46 side.
4)   Mount oil-less bearing so that it's chamfering side faces the front tip.

Wiring       diagram
                                                                  F2:white

                                                                  R2:purple


                                4            2
                    R3:black
                                3            1
                               Changeover switches                R1:orange

     Power supply cord
                                2    M2      C2

                                1    M1      C1
                               Main                               Capacitor
                               switches



                                                                  F1:black
