Image preview - the first page of the document
6822-TE


>> Download 6822-TE documenatation <<

Text preview - extract from the document
T      ECHNICAL INFORMATION
        Models No.               6822
                                                                                                       New Tool


        Description              Drywall screwdriver
                                                                                  258 (10-3-16")
CONCEPTION AND MAIN APPLICATIONS
Model 6822 is the improved version of the existing model 6820V.
Depth of driving can be adjusted only by turning Rock ring.
Removing Locator is easy to make loosening screw comfortable.




                                                                                                           178 (7")
                                                                                (2- 70
                                                                                   3/4
                                                                                       ")




    Specifications
                                                              Continuous Rating (W)              Max.
      Voltage (V)      Current (A)        Cycle (Hz)          Input           Output           Output(W)
          100              6.0               50/60             570             280                460
          115              5.2               50/60             570             280                460
          220              2.7               50/60             570             280                460
          230              2.6               50/60             570             280                460
          240              2.5               50/60             570             280                460

     No load speed                               0-4000 rpm.
     Driving shank                               6.35mm (1/4") Hex
     Max. drilling Drywall                       5mm (3/16")
     capacity      Teks                          6mm (1/4")
     Net weight                                  1.3kg (2.9lbs)
     Cord length   European countries            5.0m (16.4ft)
                   Other countries               2.5m (8.2ft)


    Standard equipment
       Phillips Insert bit 2-25
       Magnetic bit holder 635-60
       [Note] The standard equipment may differ from country to country.


    Optional accessories
       Phillips insert bit 1-25
       Phillips insert bit 2-25
       Phillips insert bit 3-25
       Magnetic bit holder 6.35-60


    Features and benefits
       1 Double insulated
       2 See the sheets attached for more information.
Improved locator and rock spring
*Depth of driving can be adjusted by
 only turning Rock ring.
*Removing Locator is easy to make
 loosening screw comfortable.




             Silent clutch




                                         Flexible Power supply cord
                                       New shape cord guard makes power
                                       supply cord more flexible.
Repair
For disassembly and assembly pay following attentions.
                                        Oil-less bearing 14   Helical gear 46              Thrust needle bearing 1023




                                           Spindle


                                                                 Collar pin 8
                                            Ring 20

   1) Mount ring 20 so that it's tapered side contacts spindle.
   2) Mount collar pin 8 so that it's width across flat faces spindle.
   3) Mount thrust needle bearing 1023 so that washer that has a thicker plate thickness should be on helical gear 46 side.
Wiring
  Follow the procedures below.
  [Europe, Oceania, South Africa, Korea]




               Motor housing



                                                                 Put all wires together in
                                                                 the lead holder under
                                                                 the switch.


                                                   Mains
                                                   switch
                                                               Noise suppressor




                           Reversing switch




  [For other countries]
    Noise suppressor does not use for all countries.
    Noise suppressor may differ from country to country.




              Motor housing




                                                            Put all wires together
                                                            in the lead holder
                                                            under the switch.

                                                   Mains
                 Earth lead wire of                switch
                 noise suppressor
                                                                Earth lead wire of
                                                                noise suppressor




                                                                   Noise suppressor

                          Reversing switch
Wiring      diagram
  [Europe, Oceania, Korea, South Africa]
                                                                  white             Field
                                                                  black
                              Mains switch
                        M2     M1
  Power supply cord
                        1 C2 2
       P1                                          orange
                                      C1
       P2
                                                                  yellow


                                                                           black
                            Noise               2 5
                            suppressor
                                                                           purple
                                               3        6
                            Earth terminal
                            (for field core)
                                                                Reversing switch




  [Other countries]
                                         red                       white        Field

                              mains switch
                         M2     M1
  Power supply cord           2
                         1 C2   C1
      P1                                               orange

       P2
                                                                     black


                            Noise                      2 5             purple
                            suppressor
                                                   3        6
                            Earth terminal
                            (for field core)
                                                                  Reversing switch




  Noise suppressor may not be used depending on countries, or in other cases,
  noise suppressor which has no earth wire would be used.
