Image preview - the first page of the document
>> Download 6834-TE documenatation <<
Text preview - extract from the document
T ECHNICAL INFORMATION
Models No. 6833, 6834
New Tool
Description Auto Feed Screwdriver
CONCEPTION AND MAIN APPLICATIONS 76mm(3")
These new auto feed screwdrivers are developed as improved
models of the current models 6830 and 6832. 6833 ... 364mm(14-3/8")
Their main new features are; - 6834 ... 396mm(15-5/8")
1. Improved design of case enabling to drive screws at the edge
only 15mm away from the wall board.
2. Tool-less System for depth adjustment of screws and taking
off the casing. 190mm(7-1/2")
3. Reverseing system of drywall screw strip.
4. More excellent tool balance for easier operation.
Model 6833 can accept 25 to 41mm screws.
Model 6834 for 25 to 57mm screws.
Specifications
Voltage(V) Current(A) Cycle(Hz) Continuous Rating(W) Max.Output(W)
Input Output
100 5.0 50/60 470 220 400
120 4.3 50/60 470 220 400
200 2.5 50/60 470 220 400
220 2.3 50/60 470 220 400
230 2.2 50/60 470 220 400
240 2.1 50/60 470 220 400
Model No. 6833 6834
No Load Speed (rpm) 4700 2800
Capacities screw strip ◦ Jabse Service Manual Search 2023 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
