Image preview - the first page of the document
6830-TE


>> Download 6830-TE documenatation <<

Text preview - extract from the document
T     ECHNICAL INFORMATION

        Models No.                6830
                                                                                                                   New Tool



        Description               Auto Feed Screwdriver

CONCEPTION AND MAIN APPLICATIONS
Model 6830 is a screwdriver with a mechanism to feedscrews
automatically. So you do not need to do bothersomeone-by-one
setting driving. Shorter tool length, well-balanced design and in-line
D-handle assures easieroperation.
(Note)                                                                   342mm(13-7/16")
This tool is not offered to some countries and areas.
Consult Makita Japan on this matter.




                                                                                                   191mm(7-1/2")
   Specifications                                                                  76mm(3")


                                                                  Continuous Rating (W)
     Voltage (V)        Current (A)         Cycle (Hz)                                        Max. Output(W)
                                                                 Input          Output
         100                5.0               50/60               470             220              400
         115                4.3               50/60               470             220              400
         200                2.5               50/60               470             220              400
         220                2.3               50/60               470             220              400
         230                2.2               50/60               470             220              400
         240                2.1               50/60               470             220              400
  Capacities
   Drywall Screw                                4mm x 25mm (5/32"x 1")
                                                4mm x 28mm (5/32"x 1-1/8")
                                                4mm x 32mm (5/32"x 1-1/4")
                                                4mm x 40mm (5/32"x 1-9/16")
   No Load Speed                                0 - 4,700 R/min.
   Net Weight                                   1.9Kg (4.2 lbs.)


   Standard equipment
   Phillips Bit 2-117 (3 pcs.), Hex Wrench 3, Plastic Carrying Case


   Optional accessories
   Phillips Bit 2-117 (5 pcs. per pkg)


  Features and benefits
   1. Double insulated
   2. Refer to the attached sheet for more information.




  The standard equipment for the tools shown may differ form country to country
                Special mechanism to allow easy
                bit installation and to prevent
                the bit from coming out unex-
                                                                      New silent clutch mechanism
                pectedly during operation.
                                                                      for quiet action
                                     Auto-feed attachment can be
                                     removed easily by loosening
                                     one screw. This allows easy
                                     bit replacement.
                                                                                     Variable speed trigger switch:
                                                                                     Handy for driving and backing
     Equipped with a dust cover to                                                   screws so simple.
     protect the gear from dust



Smooth sliding of feeder box                                                             D-handle grip configured ide-
for less fatigue of operator                                                             ally for sure, straight-line
                                                                                         driving action.

                                                     312.0                    30.0
  33.5
                                     170.0

                                                                                           Reversing switch makes it easy
         36.0




                                                                                           to back out screws.


                                                                                           Convenient carry hook can be
          Adjustable stopper plate can                                                     equipped on either side.
          be set for 3 different screw
          lengths.It also has a notch
          for easy screw centering.                                                       Hex wrench can be stored here.




          High-speed (0-4,700 rpm) for
          high efficiency
                                         Screw guide assures smooth,acc-
                                         urate feed of screw.


                     Depth adjusting knob lets you
                     drive to exact depth.No need                   Compact housing,well-balanced
                     to readjust when you change                    design:Better balance from
                     screw size.                                    positioning the motor at 45
                                                                    for easier,better driving operation
