Image preview - the first page of the document
6831D-TE


>> Download 6831D-TE documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION                                                                                       New Tool

Models No.                6831D

Description               Cordless Auto Feed Screwdriver

CONCEPTION AND MAIN APPLICATIONS
      This tool is a cordless version of the existing Model 6830
      (AutoFeed Screwdriver).
      Model 6831DH is sold with a battery cartridge 1201 but without
      a fast charger Model 6831DWH includes a battery                                   -3/8")
                                                                                340mm(13
      cartridge 1201 and a fast charger DC1201.




                                                                                                             177mm(7")
      Specifications                                                                       79
                                                                                             mm
                                                                                                 (3-
      DC magnet motor (12 V)                                                                        1/8
      Capacities                                                                                       ")

                                                4mmx25mm(5/32"x1")
                                                4mmx28mm(5/32"x1-1/8")
                   Drywall screw.
                                                4mmx32mm(5/32"x1-1/4")
                                                4mmx40mm(5/32"x1-9/16")
      No Load Speed                             2,000R/min.
      Net Weight                                2.1Kg(4.6lbs)


     Standard equipment
      Hex wrench 3, Phillips bit 2-117 (2 pcs.), Hook, Battery cartridge 1201,
      Battery cover, Fast charger DC1201 (6831DWH only), Plastic carrying case (6831DWH only)



     Optional accessories
      Phillips bit 2-117, Fast Charger DC1201, Battery cartridge 1200, 1201, 120IA.


     Features and benefits
      1.Refer to the attached sheet.




    The standard equipment for the tools shown may differ form country to country
              Special mechanism to allow easy
              bit installation and to prevent
              the bit from coming out unex-
              pectedly during operation
                                              Auto-feed attachment can be
                                              removed easily by loosening
                                              one screw.This allows easy
                                              bit replacement.
                                                                            New silent clutch mechanism for
                                                                            quiet action


    Equipped with a dust cover
                                                                                              Hex wrench can be stored here
    to protect the gear from dust




                                                                     ")                 20 (13/16")
                                                          320 (12-5/8




                                           6")
                                170 (6-11/1
                                                                                             D-handle grip configured ideally
                                                                                             for sure, straight-line driving action


     Adjustable stopper plate can
     be set for 3 different screw
     lengths.It has notches for
     easy screw centering.



Screw guide assures smooth,                      Convenient carry hook can be
accurate feed of screws                          equipped on either side

                Depth adjusting knob lets you
                drive to exact depth.No need
                to readjust when you change
                screw size.
Handling
See the Manual regarding how to handle the products and notes.


Repair
[ Notes in assembly of Screw sending mechanism ( same as #6830)]

1. No oil/grease application                                                  Ratchet disk
 If applying grease/lubricant/anti-rust oil on the rotatio n
                                                                      Leaf spring             Screw M3 Stopper
   and sliding parts, dust particles stick to them and a
   trouble will occur. Accordingly, do not use anygrease
   or oil at all.

2. Setting position of Ratchet disk
  Set Ratchet disk so that Screw M3 may be located near
   Screw M4 in Feeder box complete . ( See Fig. 1 )

3. Direction of Leaf spring( for pressing Ratchet disk)
  Install Leaf spring so that three feet may contact with               Ratchet wheel
   Ratchet disk. (See Fig. 1)
                                                                            Feeder box complete             Screw M4


                                                                                                  Fig. 1

Circuit   diagram
                                                     Switch


                                        Red
                              T+               NO           COM
                                                                                                           Red mark
                                                                   Orange
                            Battery holder

                                                                                                       Direct current motor
                              T-
                                                    Black
