68331-WW-1


>> Download 68331-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Motor Housing Complete
                                                                                                      68331


For Models           HK1800, HK1810, HK1800L
Country              All countries except Asia

Description          Motor housing complete has been changed as illustrated below.

                       Current                                                       New
                                                                                     The portion of Name plate is
                                                                                     different from the current.




 Name plate for HK1800                                      Makita Label
 or HK1810 is applied to                                    (819063-3) is
 the designated portion on                                  applied to HK1800
 each tool.                                                 or HK1810.
                             Motor housing complete                              Motor housing complete
                             without a molded Makita logo                        with a molded Makita logo
                             (157553-1)                                          (157553-1)

Interchangeability(I/C)

   Item No.          Current part                Q'ty I/C           New part             Q'ty       Note
HK1800: 054 Motor Housing Complete                          Motor Housing Complete          The part No. remains
HK1810: 053 157553-1                               1                                      1
                                                            157553-1                        the same.
HK1800L: 100
HK1800: 908                                                 Makita Label
                                                                                          1
HK1810: 907                                                 819063-3
HK1800L: 904
Interchangeability mark ;
The arrow      means that the new part is substituted for the current.

Note
Motor housing complete for replacement don't come with Name plate or Makita label.

Implementation
HK1800: From serial No. 64616E (Apr., 2003)
HK1810: From serial No. 86010E (Apr., 2003)
HK1800L: Discontinued since Apr., 2003
