Image preview - the first page of the document
68496-WW-1


>> Download 68496-WW-1 documenatation <<

Text preview - extract from the document
T
ECHNICAL INFORMATION
Subject               Change of (-) Flat Head Screw M6x22
                                                                                                      68496


For Models            HP2030, HP2032
                      All countries
Country
                      Note: This technical information applies to the products manufactured in MME.
Description           (-) Flat head screw M6x22 has been replaced by (-) Flat head screw M6x25
                      as illustrated below.

          Current                              New



               22mm                             25mm
                (7/8")                           (1")
    (-) Flat head screw M6x22      (-) Flat head screw M6x25
             (251460-1)                     (251469-3)
                                The length of the thread portion has
                                become three millimeter longer.
                                                                                    (Model HP2030)
Interchangeability(I/C)
Item No.         Current part                 Q'ty I/C            New part                 Q'ty       Note
           - Flat Head Screw M6x22                        - Flat Head Screw M6x25
    001                                         1                                            1
           251460-1                                       251469-3
Interchangeability mark ;
The arrow      means that the new part is substituted for the current.

Implementation
To be implemented since Mar.,2003 production.
