Image preview - the first page of the document
68498-WW-1


>> Download 68498-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Change of Blade Clamping System and Shoe
                                                                                                            68498
                                                                                                           (Page 1 of 3)


For Models             JR3030T
Country                All countries
Description            See below.

1) The following changes have been implemented to make the tool-less blade change system more durable.

                                                       Current
                               Spring Washer 5          Torx. Socket Head
                               (267758-6)               Shoulder Bolt M5x10
               Clamp
                                                        (266272-9)
               (310138-6)
                                                                                    Push Button
                                                                                    (162215-8)
              Pin 5.5 - 6
              (256454-1)                                                            Compression Spring 16
                                                                                    (233247-3)
              Steel Ball 4.8                                                        Ring 13
              (216002-8)               Compression Spring 3                         (257226-7)
                                       (233018-8)
               Push Pin
               (323916-5)

                                                         New

          Retaining Ring (Ext)S-18        Compression Spring 6          Shoulder Pin 5
          (961078-7)                          (233345-3)                (256471-1)            Driving Sleeve Guide
                                                                                              (417791-0)
                                                                                              Sleeve
          Driving Sleeve                                                                      (310129-7)
          (162228-9)                                                                          Push Plate
                                                                                              (345214-7)
          Pin 3
          (268094-3)                                                                          Compression Spring 2
                                                                                              (233025-1)
                                                                                              Torsion Spring 17
                                                                                              (231662-5)
                       Guide Sleeve               Pin 3
                       (331639-1)              (256158-5)


2) Slider has been changed as shown below.
                            Current                                                      New

                        Slider (168332-2)                                                Slider (168368-1)
                        Overall length: 147 mm                                           Overall length: 188.5 mm
                                        (5-3/4")                                                           (7-3/8")
                                                                 See this portion
                                                                 for distinction.
                                                                                                          68498
                                                                                                         (Page 2 of 3)

3) Shoe has been changed as shown below.
                                                   Current                                        New
        length                                90mm (3-1/2")                                  135mm (5-5/16")


                             (Shoe plate)

 Fixed shoe plate type :
 European countries
 except U.K.

                                                                                          (Welded)
                                                  Shoe                                           Shoe
                                               (168337-2)                                     (163441-2)


                                                                  Hex lock nut M5-8
                            Shoe plate
                                                                  (252103-8)
                            (344801-9)
                                                                     Spring washer 5
                                                                     (942101-7)
Movable shoe plate type:
All countries except
European countries                                                                        (Not welded)
but U.K.
                            Hex socket head bolt    Shoe supporter
                                                                                       Shoe
                            M5x50 (266241-0)        (344925-1)     (MCA product for Canada, U.S.A.,
                                                                   Mexico, Australia, New Zealand : 163442-0)

                                                                   (MJ product for U.K., South American countries,
                                                                   African countries and Asian countries: 163437-3)


4) Gear housing cover has been changed as shown below.
                           Current                                                     New
                                                              2 mm (1/16") shorter than
                                                              the current.
                                  Gear Housing Cover                                       Gear Housing Cover
                                      (317139-5)                                               (317640-0)
 Interchangeability(I/C)                                                                            68498
                                                                                                  (Page 3 of 3)
Item No.            Current part                Q'ty I/C           New part           Q'ty         Note
           Clamp
  015      310138-6                              1
           Three Bond 1377B 50g
                                                0.1g
           045082-5A
           Pin 5.5-6
  017                                            1
           256454-1
           Steel Ball 4.8
  016                                            1
           216002-8
           Push Pin
  019      323916-5                              1
           Spring Washer 5
  087      267758-6                              1
           Torx. S. H. Shoulder Bolt M5x10
  018                                            1
           266272-9
           Compression Spring 3
  020                                            1
           233018-8
           Push Button
  021      162215-8                              1
           Compression Spring 16
  022                                            1
           233247-3
           Ring 13
  023                                            1
           257226-7
                                                           Retaining Ring (Ext)S-18
  090                                                                                  1
                                                           961078-7
                                                           Driving Sleeve
  091                                                                                  1
                                                           162228-9
                                                           Pin 3
  092                                                                                  1
                                                           268094-3
                                                           Guide Sleeve                       Interchangeable
  093                                                                                  1           as a set
                                                           331639-1
                                                           Compression Spring 6
  089                                                                                  1
                                                           233345-3
  088                                                      Shoulder Pin 5              1
                                                           256471-1
                                                           Driving Sleeve Guide
  094                                                                                  1
                                                           417791-0
  096                                                      Sleeve                      1
                                                           310129-7
                                                           Push Plate
  097                                                                                  1
                                                           345214-7
                                                           Compression Spring 2
  098                                                                                  1
                                                           233025-1
                                                           Torsion Spring 17
  099                                                                                  1
                                                           231662-5
                                                           Pin 3
  095                                                                                  1
                                                          256158-5
           Slider                                         Slider
  038                                            1     No                              1
           168332-2                                       168368-1
  001      Shoe                                  1     No Shoe                         1
           168337-2                                       163441-2
           Shoe Plate
  004      344801-9                              1
           Hex. Socket Head Bolt M5x50
  002                                            1
           266241-0
  003      Hex. Lock Nut M5-8                    1
           252103-8
           Spring Washer 5                                                                   See page 2.
  084      942101-7                              1
           Shoe Supporter
  006                                            1
           344925-1
                                                          Shoe                         1
                                                          163437-3
  100                                                     Shoe
                                                                                       1
                                                          163442-0
           Gear Housing Cover                             Gear Housing Cover
  030                                            1     No                              1
           317139-5                                       317640-0
 Implementation
To be implemented from Jul., 2003 production.
