Image preview - the first page of the document
68674-WW-1


>> Download 68674-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Inner Flange 40
                                                                                                           68674


For Models            5007B, 5007NB, 5007NBA, 5007NH, 5007S, 5026D, 5036D, 5046D, 5057KB, 5611D, 5620D,
                      5621D, 5621RD, 5630D, 5820, BLS712, BSS730, LS0711B, LS0713, LS0713F, LS711D, M513,
                      M514, M517
Country               All countries except Canada, U.S.A., Chile, Mexico, Panama, and European countries.
                      Note: This technical information applies to the products using Inner flange 40 of 20mm(13/16")
                            arbor.
Description           Inner flange 40 has been changed as illustrated below.

                        Current                                                       New


                                                20mm                                                  20mm
                                               (13/16")                                              (13/16")




                                                               Mark for distinction from the       1.2mm
                                          1.4mm
                                                               current.
                      Inner Flange 40                                              Inner Flange 40
                        (224199-9)                                                    (224397-5)

Interchangeability(I/C)
 Item No.        Current part                  Q'ty I/C            New part                  Q'ty         Note
           Inner Flange 40                                 Inner Flange 40
See below.                                       1                                            1
           224199-9                                        224397-5
Interchangeability mark ;
The arrow      means that the new part is substituted for the current.

Item No. of Inner flange 40
  5007B     5007NB 5007NBA 5007NH 5007S                   5026D 5036D     5046D    5057KB    5611D    5620D 5621D
   023            024        003   023                           051                 053      001      003   044
 5621RD     5630D    5820     BLS712    BSS730       LS0711B   LS0713    LS0713F    LS711D     M513 M514         M517
    041      044      019      056       003                      006                 056           023          019

Implementation
5007NB: From Jun., 2003 production.
BLS712, BSS730, LS0711B, LS0713, LS0713F, LS711D: From Oct., 2003 production.
5007NBA, 5621RD: From Oct., 2003 production or later.
5007B: Discontinued since Oct., 1993.
5611D: Discontinued since May, 1995.
5820: Discontinued since May, 1999.
M513, M514: Discontinued since Jun., 1991.
M517: Discontinued since Apr., 1993.
5007NH, 5007S, 5026D, 5036D, 5046D, 5057KB, 5620D, 5621D, 5630D: To be informed later.
