Image preview - the first page of the document
68797-WW-1


>> Download 68797-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                 Change of Spindle, Gear Complete, etc.
                                                                                                                  68797


For Models              6833, 6834, 6835D, 6836

Country                 All countries
Description             Needle bearing has been added into the inside of Spindle.
                        Consequently the relevant parts have been changed as illustrated below.

                         Current                                                          New
          Flat washer 6 (1pc.)          Gear complete                       Flat washer 8 (2pcs.)      Gear complete

      Compression spring 5                                           Compression spring 8




                   Spindle                                        Spindle complete

                                                                               (Needle bearing)

Interchangeability(I/C)
Item No.         Current part              Q'ty I/C         New part                 Q'ty                  Note
            Compression Spring 5                    Compression Spring 8
    036                                     1    No                                   1
            233096-8                                233393-2
            Flat Washer 6                           Flat Washer 8                                           Interchangeable
    037                                     1    No                                   2
            267184-9                                267277-2                                                     as a set
            Spindle                                 Spindle Complete                        For European countries,
    035                                     1    No                                   1
            323765-0                                153741-8                                Reunion, South Africa
            Spindle                                 Spindle Complete                        For all countries except
    035                                     1    No                                   1
            323760-0                                153735-3                                European countries,
                                                                                            Reunion, South Africa
            Gear Complete                           Gear Complete
    039                                     1    No                                   1     For 6833, 6835D
            152997-0                                153737-9
            Gear Complete                           Gear Complete
    039                                     1    No                                   1     For 6834
            152995-4                                153739-5
            Gear Complete                           Gear Complete
    039                                     1    No                                   1     For 6836
            152998-8                                153736-1

Implementation
6833, 6834, 6835D: To be implemented since Feb., 2004 production.
6836: From serial No. 3983E (Aug., 2003)
