Image preview - the first page of the document
6891D-TE


>> Download 6891D-TE documenatation <<

Text preview - extract from the document
T   ECHNICAL INFORMATION
     Models No.              6891D
                                                                                                              New Tool


     Description             Cordless screw driver



CONCEPTION AND MAIN APPLICATIONS                                                  55
  Model 6891D/6891DW are screw drivers
  with 9000 batteries used only for dry walls.
  Each of them has a variable speed switch with a brake.
  Model 6891DW consists of :
   6891D (Battery screw driver for boards)




                                                                                             260
   DC9100 (Quick charger)
   Battery 9000
  The battery and the charger are not attached to Model 6891D.



                                                                           230




  Specifications

  Motor                                               DC 9.6 V magnet motor
  No load speed                                       0-1400/min
  Hexagon shaft                                       6.35mm (across flats)
  Dry wall screw                                      4mm
  Net weight                                          1.3 kg



  Standard equipment
  Magnet connecting bit 6.35-60 : 1
  Bit 2-25 : 1
  Steel portable case only for 6891DW


  Optional accessories
  Battery 9000
  Magnetic connecting bit 6.35-60
  Bit 2-25
  12V quick charger DC9012 (for charging from the car cigarette lighter socket)           Hatching part is narrowed




                                                                 Stopper
                                                                            Finger hold



  The standard equipment for the tools shown may differ form country to country
Features and benefits
 (1) Stopper allows you to tighten screws to any depth. The stopper can be adjusted easily with its screw for fine
 control.
 (2) Dust-proof ring rotates with the bit to prevent dust from going into the machine.
 (3) Brake to stop the rotation instantly enables you to attach screws to the bit soon during your continuous operation.
 (4) Magnetic connecting bit prevents screws from falling off.
 (5) Over-current relay (automatic-reset type) protects
     the motor and the switch.
 (6) Finger hold over the switch and the neck on the joint of
    the handle allow you to hold the machine in balance and
    operate the switch smoothly.
Repair
(1) Before placing the gear complete in the housing,
    attach the dust-proof ring on the tip of the gear.
(2) Grease the front part of the ball bearing
    (to protect the bearing from dust coming into
    the without being eliminated by the dust-proof ring).


                                                                      Gear complete




                                                                             Dust-proof ring
                                                                         Grease

                                                            Housing
