Image preview - the first page of the document
6904VH-TE


>> Download 6904VH-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION
       Models No.           6904VH
                                                                                                                         New Tool


      Description           Impact Wrench
                                                                                                265 mm (10-3/8")
CONCEPTION AND MAIN APPLICATIONS
   Model 6904H/VH was developed as an improved version of
   Model 690(discontinued). More compact, lightweight and




                                                                     184 mm (7-1/4")
   well-balanced for increased maneuverability. Mode 6904H
   and Model 6904VH are the same except the tool speed.


          Model               Tool speed
                                                                                                                         64 mm (2-1/2")
          6904H               Single speed
          6904VH              Two variable speeds



   Specifications
                                                                Continuous Rating (W)
       Voltage (V)       Current (A)         Cycle (Hz)                                                Max. Output(W)
                                                               Input          Output
           100               3.8               50/60             360             160                               290
           115               3.3               50/60             360             160                               290
           200               1.9               50/60             360              160                              290
           220               1.7               50/60             360              160                              290
           230               1.7               50/60             360              160                              290
           240               1.6               50/60             360              160                              290
    Capacities
    Standard Bolt                       M10- M16 (3/8"-5/8")
     High Tensile Bolt                  M10- M12 (3/8"-7/16")
     Self-Drilling Screw                6mm(1/4") ---- Model 6904VH only
     Square Drive                       12.7mm(1/2")
     Net weight                         1.8 Kg (4.0 1bs)


      Model No                               6904H                                     6904VH
      No Load Speed (RPM)                    2,400                   High 0-2,400
                                                                     Low 0-2,100
      Impact per Min.                        3,000                   High 0-3,000
                                                                     Low 0-2,500
      Fastening Torque           2,000 Kg. cm (145 ft 1bs)   High 2,000 Kg.cm (145 ft. 1bs)
                                                             Low 1,500 Kg.cm (109 ft. 1bs)


   Standard equipment
      Socket 17-39, 21-41, 26-45, Steel Carrying Case


   Optional accessories
    Various size of Socket, Extension Bar, Universal Joint, Bit Adapter (for Model 6904VH only), Various size Phillips
    Bits (for Model 6904VH only), Socket Bits 8-55, 3/8"-55 (for Model 6904VH only)




The standard equipment for the tools shown may differ form country to country
Features and benefits
 1.Very compact, lightweight (only 1.8 kg; 4.0 lbs) and well-balanced for increased maneuverability
 2.Double insulated for operator safety
 3.Comes with steel carrying case
 4.Reversing feature

 The following features are for Model 6904VH only.
 5.Tow speeds enable you to fasten wider range of bolts and nuts.
 6.Variable speed and bit adapter (optional accessory) allow easy fastening of long wood screws.
