Image preview - the first page of the document
6908D-TE


>> Download 6908D-TE documenatation <<

Text preview - extract from the document
T       ECHNICAL INFORMATION                                                                                              New Tool

         For Models              6908D
         Description             Cordless Impact Driver


CONCEPTIONimpact driver is upgraded version of existing
  This 9.6V cordless
                     AND MAIN APPLICATIONS                                                               171mm (6-3/4")

    Model 6903VD and its brief benefits are;
    *Faster driving speed
    *More number of driving screws from a single charge




                                                                                        232mm (9-1/8")
    *Compact design and good balance
    *Lower vibration and lower noise
    *Motor is more endurable and longer life.
    *Carbon brushes can be replaced without dis-assembling housing.
    *New switch has wider area of stroke for variable speed so that
     speed control becomes easier.                                                                                                         ")
                                                                                                                                    m (3
    *Reversing switch button located at the top of the handle so that                                                       77m
     user can change direction easily leaving the other hand free.
    *Battery 9122(2.0Ah) can be removed easily by pushing buttons.


      Model                          Battery(2.0Ah)                 Fast charger                            Plastic carrying case
      6908DA                         Battery9122                    No                                      No
      6908DWA                        Battery9122                    DC1410                                  Yes


   Specifications
      Motor                                                         DC 9.6V magnet motor
      Battery                                                       Battery 9122(Ni-Cd, 9.6V, 2.0Ah)
      No load speed                                                 0~2200rpm
      Impacts per minute                                            0~2800
      Max. tightening torque                                        800kgf.cm (700in.lbs)
      Capacities                    Machine screw                   M4~M8(5/32"~5/16")
                                    Standard bolt                   M4~M12(5/32"~1/2")
                                    High tensile bolt               M5~M10(3/16"~3/8")
                                    Coarse thread                   22~90mm(7/8"~3-1/2")
                                    Self drilling                   M4~M6 x 13~45mm(5/32"~1/4" x 1/2"~1-3/4")
      Net weight                                                    1.4kg (3.1lbs)



   Standard        equipment
      Phillips Bit 2-65...1pc. Battery Cover...1pc. Set Plate(to use battery without push buttons)...1pc.
      Plastic Carrying Case(6908DWA only)...1pc.


   Optional     accessories
       Phillips Bit 2-65, 3-65    Bit Piece
       Socket Bit 7-55, 8-55, 10-55, 10-70, 12-86, 13-55, 14-55, 17-55
       Keyless Drill Chuck       Drill Chuck
       Battery 9100, 9102, 9122, 9102A      Fast Charger DC1201, DC1209, DC1410




    The Standard equipment for the tools shown may differ from country to country.
    Features       and benefits
    See the sheets attached for more information.

 Fastest driving speed Most number           Ergonomic design
 of driving screws among the same            for easy operation
 class models
                                             Handle shaped
                                             ergonomically
                                             and well balanced

                                                                     Lowest vibration and loweast noise




                                            Length : 171mm(6-3/4")




                                                                              More endurable and longer
                                                                              life motor
                                                                              Carbon brushes can be replaced
                                                                              twice till motor is worn out.
                   Center height
                   26mm (1-1/32")


            Alunminum
            Hammer Case


Push button for reversing
direction of rotation
can be actuated easily leaving
the other hand free




                                                                        Battery 9122(2.0Ah)
New variable speed control switch                                       *can be removed easily by pushing buttons
makes speed control easiest in the world.                               *New high capacity battery
                                                                        *Battery without push buttons can be used with
                                                                        set plate(standard accessory) .
Caution
Please refer to the instruction manual for Model 6908DW.




Repair
(1) How to dismount the housing R and L
    Dismount the housing after taking off the hammer case.




                                                                           Compression spring
(2) How to dismount the bit holder                                                                 Steel ball
                                                             Ring spring             Sleeve Groove
    Bit holder is constructed as illustrated right.
    Take off the ring spring, and then bit holder
    can be dismounted.
    After dismounting of bit holder, the anvil
    can be dismounted from the hammer case.
                                                                Flat washer                     Anvil




                                                                                        Flat washer
(3) How to mount the flat washer                                                               Anvil
    The flat washer has to be mounted between
    hammer case and anvil.
    In this case, the chamfered part on the flat washer         Chamfered part
    has to face the anvil as illustrated right.


                                                                                              Hammer case




                                                                                           Spindle
(4) How to dismount the hammer                                        Swelling part                   Cum groove top
    Adjust the open part for steel ball on hammer
    with the top of groove on spindle pressing
    the hammer with arbor press.
    Then the steel ball can be taken off
    in order to dismount the hammer.                                                                     Hammer


                                                               Steel ball
                                                               insert entrance
                                                                                                         Gear
 (5) Fastening of screws
     The screws have to be fastened as follows.

      Parts to be fastened with screws     Fastening Torque
      Housing                              13-18 kg.cm (11-15 in.lbs)
      Hammer case                          18-22 kg.cm (15-18 in.lbs)
      Motor                                6-10 kg.cm (5-8 in.lbs)
      Fastening for the hammer case has to be carried out
      according to the diagonal order.




Circuit   diagram



                                                   Red
         T+                              M1
Spring terminal                 Switch                                            Direct current motor

          T-                             M2
                                                   Black




                                         6908D Circuit diagram




Interchangeability
The following spare parts have can interchangeability with the existing models.
      Parts Name                     Existing models
      Sleeve
      Compression Spring 13
      Flat Washer 12                      6903V
      Ring Spring 11
      Steel Ball 5.6
      Hand Strap                          6911D
      Anvil                               6913D
