6902D-TE


>> Download 6902D-TE documenatation <<

Text preview - extract from the document
T      ECHNICAL INFORMATION
        Models No.               6902D
                                                                                                    New Tool


        Description              Cordless Impact Wrench



CONCEPTION AND MAIN APPLICATIONS
      Exceptionally high torque for cordless impact wrench.
      It generates tightening power as high as conventional corded
      impact wrench.




    Specifications



      Motor                                                   DC14.4V Magnet Motor
      Net Weight            Body only                         1.2Kgs.
                            With Battery                      2.5Kgs.
      No Load Speed         R.P.M.                            1,900 rpm
                            Impacts per min.                  2,300
Capacity
    Tightening capacity            Standard bolt (4T) M12 to M16
                                   Hi-tension bolt (F8 to 11T)
     Max torque                    1,500 Kg/cm (by M16 (F10T) for five seconds)
     Number of tightening          (190 pcs. Of Standard bolt M12 for 3 seconds ea.)
     with full charged
     battery                       (1,500 pcs. Of Standard bolt M12 for 0.3 seconds ea.)


    Standard equipment
    Steel carrying case
    Battery No. 1401
    Charger No. DC1401


    Optional accessories
     See Makita general catalog for various sizes of socket , universal joint, bit adapter, etc..


    Features and benefits
    1.Powerful 1,500 Kg .cm toque
    2.Could replace your corded impact wrench.
    3.Large capacity of battery 14.4V
    4.Fastens as many as 190 pcs.of bolts
    5.Both shoulder strap and waist belt equipped with battery
    6.Fit securely around your waist.
    7.With overload protection
    8.Cuts out to break the circuit for battery protection.

The standard equipment for the tools shown may differ form country to country
