Image preview - the first page of the document
6916D-TE


>> Download 6916D-TE documenatation <<

Text preview - extract from the document
T       ECHNICAL INFORMATION
      Models No.            6916D
                                                                                                             PRODUCT
                                                                                                                 P1/6

       Description          Cordless impact driver
                                                                                                      L
CONCEPTION AND MAIN APPLICATIONS
The above model is Cordless Impact Drivers designed for
much reduced weight and more compact body, and this model features
the lightest weight and the shortest overall length in this class.
Model 6916D is powered by 12V battery, and features
powerful max. torque at 100N.m.

  Variations of Model 6916D are as follows.
                                                             Plastic                                                H
  Model No.               Battery                 Charger Carrying Case
6916DWA         1222 /1 pc.    Ni-Cd, 2.0Ah       DC1411       Yes
6916DWAE        1222 /2 pcs. Ni-Cd, 2.0Ah         DC1411       Yes
6916DWD         1234 /1 pc.  Ni-MH, 2.6Ah         DC1411       Yes
6916DWDE        1234 /2 pcs. Ni-MH, 2.6Ah         DC1411       Yes
6916DWF         1235 /1 pc.  Ni-MH, 3.0Ah         DC1411       Yes
6916DWFE        1235 /2 pcs. Ni-MH, 3.0Ah                      Yes                               W
                                                  DC1411
                Ni-Cd; Nickel Cadmium battery                                                    Dimensions : mm ( " )
                Ni-MH; Nickel-Metal Hydride battery                                         Width ( W )   94 (3-11/16)
                                                                                            Height ( H ) 231(9-1/8)
   Specification                                                                            Length ( L ) 168 (6-5/8)
               Voltage (V)                        D/C 12 V
      No load speed (min-1=rpm)                       0 - 2,300
      Impact per minute (min-1=bpm)                   0 - 3,000
                 Hex. shank : mm ( " )             6.35 (1/4)
                 Machine screw              M4 - M8 (5/32" - 5/16")
      Capacities
                 Standard bolt              M5 - M12 (3/16" - 15/32")
                 High Tensile bolt          M5 - M10 (3/16" - 3/8")
                 Self drilling screw
