Image preview - the first page of the document
6910-TE


>> Download 6910-TE documenatation <<

Text preview - extract from the document
T      ECHNICAL INFORMATION
        Models No.               6910
                                                                                                             New Tool


        Description              10-TYPE IMPACT WRENCH

CONCEPTION AND MAIN APPLICATIONS
The electric tool for fastening/loosening of High tensile
bolts which are demanded more and more recently.
We developed, as one of Impact Wrench series (#6904,
6906), to make it stronger and available for fastening
High tension bolts M22 and M24.



   Specifications
    Motor                              Series commutator motor
    Voltage                            100V
    Current                            15A
    Frequency                          50-60Hz
    Consumed power                     1300W
    Rated output                       650W
    Max. Output                        800W
    Rotation                           5200/min
    No load speed                      1400/min
    Hitting stroke                     1500 /min
    Fastening torque                   10000kgs. cm
    Functional size                    Bolt size M22, M24 (W 7/8, W 1)
                                       Square drive     25.4 mm


   Capacity
    Overall length(size)       389mm
    Weight                     9kgs
    Cord length                2.5m


   Equipment
   Standard equipment:
      Socket 41-71-------------1pc
      Steel case-----------------1pc
      Hex. Rod spanner5------1pc
      Side grip------------------1pc
   Optional accessories:
      (1) Socket 35-69
      (2) Socket 36-69

         Socket size                    Bolt size(High tension bolt)                          Socket outer shape
    Hex. Double face width Metric screw          Inch screw                  Length             Outer diameter
             35                 --                  M7/8                       69                     54
             36                M22                   --                        69                     56
             41                M24                   W1                        71                     63
   (NOTE) Socket 41 belongs to standard equipment.


      (3) Extension bar 25.4 (7852035)
          The socket extension bar is usable in a narrow space or in a place where Socket cannot reach.
Features   and benefits
  1) As the strong fastening performance , fastening torque 10000 kg
