Image preview - the first page of the document
69281-WW-1


>> Download 69281-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Addition of Vendor for Battery Charger DC1804
                                                                                                             69281


For Models           6343D, 8443D
Country              European countries
                     Note: This technical information applies to the tools manufactured at MME.
Description          In parallel with TAMURA-made DC1804, FRIWO-made DC1804 has become available.
                     FRIWO's battery charger can be stored in the plastic carrying case for models 6343D and 8443D.
                     However FRIWO's component parts don't have interchangeabilty with TAMURA's.

                     Therefore, see the list of "Interchangeability(I/C)" for the detail and choose either FRIWO's
                     component parts or TAMURA's by the check of the following mark.


                                    Mark for distinction of FRIWO-made DC1804
                                                   in the name plate




Interchangeability(I/C)

Item No.        Current part               Q'ty I/C         New part                    Q'ty             Note
                                                                                               For European countries
           DC1804 Battery Charger                     DC1804 Battery Charger                   except U.K.
    F01                                     1   Yes                                      1
           193827-6                                   193827-6                                 Part No. remains the same.
           DC1804 Battery Charger                     DC1804 Battery Charger                   For U.K.
    F02                                     1   Yes                                      1
           193828-4                                   193828-4                                 Part No. remains the same.
           Charger Case Complete                      Charger Case Complete
    002                                     1    No                                      1
           153713-3                                   153768-8
           Charger Case Cover                         Charger Case Cover
    004                                     1    No                                      1
           418339-1                                   418346-4
                                                                                                For European countries
           Battery Box                                Battery Box
    007                                     1   Yes                                      1
           418392-7                                   418347-2
           Circuit Board                              Circuit Board
    006                                     1    No                                      1
           631566-5                                   631568-1
           Vinyl Cord 0.75-2-2.0                                                                For European countries
                                                      Vinyl Cord 0.75-2-2.0
    003    CEE(13-52)                       1   Yes                                      1
                                                      667822-7                                  except U.K.
           667985-9
           Vinyl Cord 0.75-2-2.0                      Vinyl Cord 0.75-2-2.0
    003    BASEC                            1   Yes                                      1             For U.K.
                                                      667823-5
           667986-7

Implementation
From around Sep., 2003 production
