Image preview - the first page of the document
69295-WW-1


>> Download 69295-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Spring Terminal
                                                                                                               69295
                                                                                                           (Page 1 of 2)


For Models           M645D, M646D, M647D, SC161D, SC190D, 6203D, 6204D, 6213D, 6214D, 6216D, 6226D,
                     6227D, 6228D, 6233D, 6236D, 6313D, 6314D, 6316D, 6327D, 6328D, 6333D, 6336D, 6343D,
                     6503D, 6908D, 6909D, 6914D, 6916D, 6916FD, 6917D, 6918D, 6918FD, 6960D, 6970D, 6990D,
                     6991D, 6992D, 8413D, 8433D, 8443D
Country              All countries
Description          Spring terminals have been modified to improve durability as illustrated below.
                     Part numbers remain the same.

                        Current                                                         New
     Spring Terminal (+)        Spring Terminal (-)             Spring Terminal (+)           Spring Terminal (-)
        (654168-0)                 (654169-8)                      (654168-0)                    (654169-8)


                                                                               Addition
                                                                                of slits



                                                                18 mm                         18 mm
                                                               (11/16")                      (11/16")

                                                                                 0.8 mm                         0.8 mm
                                                                                 (1/32")                        (1/32")


Interchangeability(I/C)
Item No.      Current part                Q'ty I/C           New part                 Q'ty              Note
   See Spring Terminal (+)                            Spring Terminal (+)
                                           1                                            1
  below. 654168-0                                     654168-0
   See Spring Terminal (-)                            Spring Terminal (-)
                                           1                                            1
  below. 654169-8                                     654169-8
Interchangeability mark ;
 The arrow      means that the new part is substituted for the current.

Item No. of Spring Terminal (+)
 Model M645D          M646D      M647D SC161D SC190D             6203D      6204D      6213D      6214D        6216D
Item No.               011               030    044               011        007        022        007          010
 Model      6226D     6227D      6228D      6233D      6236D     6313D      6314D      6316D      6327D      6328D
Item No.                        011                     009       022        007        010               011
 Model      6333D     6336D       6343D     6503D     6908D       6909D     6914D      6916D      6916FD       6917D
Item No.     011       009         005       010                                        011
 Model      6918D     6918FD      6960D     6970D      6990D      6991D     6992D      8413D      8433D        8443D
Item No.            011            012                         011                                 005

Item No. of Spring Terminal (-)
 Model M645D          M646D      M647D SC161D SC190D             6203D      6204D      6213D      6214D        6216D
Item No.               012               032    046               012        018        021        018          011
 Model      6226D     6227D       6228D     6233D      6236D     6313D      6314D      6316D      6327D      6328D
Item No.                       012                      010       021        018        011               012
 Model      6333D     6336D       6343D     6503D     6908D       6909D     6914D       6916D     6916FD       6917D
Item No.     012       010         006       011                                      012
 Model      6918D     6918FD      6960D     6970D      6990D     6991D      6992D      8413D      8433D        8443D
Item No.            012            011       012                  010                              006
                                                                                               69295
                                                                                             (Page 2 of 2)


 Note
This technical information applies to the machines manufactured at MJ, MCA, MCC, MKC, MME

 Implementation
The following models: As soon as the current parts run out
M645D, M646D, M647D, SC161D, SC190D, 6203D, 6204D, 6213D, 6214D, 6216D, 6226D, 6227D, 6228D,
6233D, 6313D, 6314D, 6316D, 6327D, 6328D, 6333D, 6336D, 6343D, 6503D, 6908D, 6914D, 6916D, 6916FD,
6917D, 6918D, 6918FD, 6960D, 6970D, 6990D, 6991D, 8413D, 8433D, 8443D

6236D: Discontinued since Feb., 2003
6909D: Discontinued since Jan., 2003
6992D: Discontinued since Sep., 2003
