Image preview - the first page of the document
69302-WW-1


>> Download 69302-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Addition of Gear Assembly
                                                                                                             69302

For Models            BFH040, BFH040F, BFT040F, BFH090, BFH090F, BFH120F, BFT122F, BFT123F
Country               All countries
Description           Gear assembly C, D and E have become available for repair.
                      Each gear assembly consists of Spindle, Gear case complete, Clutch, Gear, etc.
                      And there is/are model No. label(s) on the gear assemblies.
                      Gear assembly C/E has the label(s) of the correspondent model(s) as illustrated below.
                      Gear assembly D has the two labels of the representative models.
                      See the following chart.



                           Label position A                                   Label position B




                                                   Gear Assembly C
                                                     (125191-7)

                                                          Label
                             Description                                           For model
                                                 Position A   Position B
                           Gear Assembly C       BFL121F       BFT080F        BFL121F, BFT080F

                                                                              BFH040, BFH040F,
                                                                              BFH090, BFH090F,
                           Gear Assembly D       BFL200F        BFT122F
                                                                              BFH120F, BFT122F,
                                                                              BFT123F, BFL200F
                           Gear Assembly E       BFT040F                           BFT040F

Interchangeability(I/C)
      Item No.               Current part         Q'ty I/C        New part               Q'ty            Note
    BFL121F: 066                                              Gear Assembly C
                                                                                          1     BFL121F, BFT080F
    BFT080F: 063                                              125191-7
BFL200F: 066
                                                                                                BFH040, BFH040F, BFH090,
BFT122F, BFT123F: 063                                         Gear Assembly D
BFH040, BFH040F, BFH090,
                                                                                          1     BFH090F, BFL200F,
                                                              125192-5                          BFH120F, BFT122F, BFT123F
BFH090F, BFH120F: 072
                                                              Gear Assembly E
    BFT040F: 063                                                                          1           BFT040F
                                                              125231-1

Implementation
Available since Sep., 2003
