Image preview - the first page of the document
6931D-TE


>> Download 6931D-TE documenatation <<

Text preview - extract from the document
T       ECHNICAL INFORMATION
          Models No.              6931D
                                                                                                              New Tool


          Description             Battery powered impact wrench
                                                                                            225mm

CONCEPTION AND MAIN APPLICATIONS
The number of impacts can be set on the wrench with the
counter switch, which automatically stops its operation after the
preset number of impacts are given. Because of this feature, you
can tighten bolts at the constant torque with this impact wrench.




                                                                                                                  235mm
The model 6931DW is compored with 6931D,charger DC1401
and Battery 1402.


                                                                                                       60mm




    Specifications
      Motor                               DC14.4V Magnetic Motor
      No Load Speed                       0 -1,900 r.p.m.
      Impacts per minute                  0 - 2,300/min.
      Anvil size                          1/2" (12.7mm)
      Net Weight                          1.6 Kg


     Impact number setting range : 4 to 196 impacts (Set with the counter switch at 02 to 98.)
     Tightening torque (max.) 1500kgf-cm (108 ft-lbs)
     Tightening capacity : Regular bolts M12 to M16 (1/2
