Image preview - the first page of the document
69583-WW-1


>> Download 69583-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Torque Indication on Plate
                                                                                                               69583


For Models            BFL080F, BFL121F, BFL200F, BFT040F, BFT080F, BFT122F

Country               All countries

Description           Hard joint torque indication on Plate has been changed to a soft joint torque indication.


                   5 digit ID number
                                                                            Current                   New
                                                          For Model           Indication of Torque (Color)
                                                          BFL080F       2 - 8Nm (Yellow) 2 - 7.5Nm (Yellow)
                                                          BFL120F       5 - 12Nm (Blue)      5 - 12Nm (Blue) *
                                                          BFL121F       5 - 12Nm (Blue)      5 - 11.5Nm (Green)
                                                          BFL200F       8 - 20Nm (Red)       8 - 18Nm (Red)
                                                          BFT040F       1 - 4Nm (Yellow) 1 - 3.5Nm (Yellow)
                 Indication of Torque                     BFT080F       3 - 8Nm (Blue)       3 - 6.5Nm (Blue)
                                                          BFT122F       5 - 12Nm (Red)       5 - 10Nm (Green)
     Note:
     New 5 digit ID number starts from No. 10000.         BFT123F       5 - 12Nm (Red)       5 - 12Nm (Red) *
                                                                                          * This remains the same.
Interchangeability(I/C)

Item No.      Current part              Q'ty I/C       New part                 Q'ty                 Note
           Plate A                                 Plate A
    050                                  1   No                                  1     For BFL080F
           345282-0                                345402-6
           Plate B                                 Plate J                             For BFL121F
    050                                  1   No                                  1
           345283-8                                345406-8                            (Plate B is still used for BFL120F.)
           Plate C                              Plate C
    050                                  1   No                                  1     For BFL200F
           345284-6                             345401-8
           Plate G                              Plate G
    001                                  1   No                                  1     For BFT040F
           345343-6                             345403-4
           Plate H                              Plate H
    001                                  1   No                                  1     For BFT080F
           345344-4                             345404-2
           Plate I                                 Plate K                             For BFT122F
    001                                  1   No                                  1     (Plate I is still used for BFT123F.)
           345345-2                                345405-0

Implementation
BFL080F: From serial No. 3520E (Oct., 2003)
BFL121F: From serial No. 3138E (Oct., 2003)
BFL200F: From serial No. 3761E (Oct., 2003)
BFT040F: From serial No. 1936E (Oct., 2003)
BFT080F: From serial No. 1928E (Oct., 2003)
BFT122F: From serial No. 1810E (Oct., 2003)
