Image preview - the first page of the document
69669B-WW-1


>> Download 69669B-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Change of Battery Charger
                                                                                                         69669B
                                                                                                        (Page 1 of 4)

For Models             Several models
Country                All countries
Description            Several Battery chargers have been unified to DC1414(Makita Brand)/LG-126(Dolmar Brand)
                       Battery charger set as illustrated below.

                        Current                                          New




             DC1201                     DC9700




                                                                   DC1414, LG-126


 DC9710, DC9711, DC1470                 LG-124

Interchangeability(I/C)
Item No.          Current part            Q'ty I/C           New part               Q'ty                Note
           DC1470 Battery Charger Set                DC1414 Battery Charger Set
                                           1                                         1      U.S.A.
           193621-6                                  193870-5
           DC1470 Battery Charger Set                DC1414 Battery Charger Set
                                           1                                         1      Canada
           193622-4                                  193870-5
           DC1470 Battery Charger Set                DC1414 Battery Charger Set
                                           1                                         1      Panama, Guam
           193095-1                                  193871-3
           DC1470 Battery Charger Set                DC1414 Battery Charger Set            Bolivia, Brazil(220V), Chile,
                                           1                                         1     Guyana, Paraguay, Peru, Uruguay,
           193087-0                                  193864-0
                                                                                           Austria, France, Germany, Italy,
                                                                                           Netherlands, Poland, Russia,
                                                                                           Spain, Sweden, Switzerland,
                                                                                           Bhutan, Syria, Algeria,
                                                                                           Canary Islands, Congo, Egypt,
                                                                                           Gabon, Morocco, Reunion,
                                                                                           South Africa, North Korea,
                                                                                           New Caledonia, Tahiti
           DC1470 Battery Charger Set                DC1414 Battery Charger Set            Saudi Arabia(220V), Turkey,
                                           1                                         1     Indonesia, Philippines, Thailand,
           193096-9                                  193864-0
                                                                                           Vietnam
           DC1470 Battery Charger Set                DC1414 Battery Charger Set
                                           1                                         1      Dominica, U.K.
           193088-8                                  193865-8
           DC1470 Battery Charger Set                DC1414 Battery Charger Set            Kuwait, Hong Kong, Malaysia,
                                           1                                         1
           193097-7                                  193865-8                              Singapore
           DC1470 Battery Charger Set                DC1414 Battery Charger Set
                                           1                                         1      Australia, New Zealand
           193089-6                                  193866-6
           DC1470 Battery Charger Set                DC1414 Battery Charger Set
                                           1                                         1      Brazil(110V)
           193093-5                                  193869-0
           DC1470 Battery Charger Set                DC1414 Battery Charger Set
                                           1                                         1      Korea
           193091-9                                  193868-2
           DC1470 Battery Charger Set                DC1414 Battery Charger Set
                                           1                                         1      China
           193090-1                                  193867-4
           DC1470 Battery Charger Set                DC1414 Battery Charger Set
                                           1                                         1      Argentina
           193094-3                                  193873-9
           DC1470 Battery Charger Set                DC1414 Battery Charger Set
                                           1                                         1      Saudi Arabia(127V), Taiwan
           193092-7                                  193877-1
                                                                                                         69669B
                                                                                                        (Page 2 of 4)

Item No.          Current part          Q'ty I/C           New part             Q'ty                Note
           DC9710 Battery Charger Set              DC1414 Battery Charger Set
                                         1                                       1      U.S.A.
           193619-3                                193870-5
           DC9710 Battery Charger Set              DC1414 Battery Charger Set
                                         1                                       1      Canada
           193620-8                                193870-5
           DC9710 Battery Charger Set              DC1414 Battery Charger Set
                                         1                                       1      Panama, Guam
           193083-8                                193871-3
           DC9710 Battery Charger Set              DC1414 Battery Charger Set
                                         1                                       1      Panama, Guam
           193190-7                                193871-3
           DC9710 Battery Charger Set              DC1414 Battery Charger Set          Bolivia, Brazil(220V), Chile,
                                         1                                       1     Guyana, Paraguay, Peru, Uruguay,
           193075-7                                193864-0
                                                                                       Austria, France, Germany, Italy,
                                                                                       Netherlands, Poland, Russia,
                                                                                       Spain, Sweden, Switzerland,
                                                                                       Bhutan, Syria, Algeria,
                                                                                       Canary Islands, Congo, Egypt,
                                                                                       Gabon, Morocco, Reunion,
                                                                                       South Africa, North Korea,
                                                                                       New Caledonia, Tahiti
           DC9710 Battery Charger Set              DC1414 Battery Charger Set           Saudi Arabia(220V), Turkey,
                                         1                                       1      Indonesia, Philippines, Thailand,
           193084-6                                193864-0
                                                                                        Vietnam
           DC9710 Battery Charger Set              DC1414 Battery Charger Set          Bolivia, Brazil(220V), Chile,
                                         1                                       1     Guyana, Paraguay, Peru, Uruguay,
           193187-6                                193864-0
                                                                                       Austria, France, Germany, Italy,
                                                                                       Netherlands, Poland, Russia,
                                                                                       Spain, Sweden, Switzerland,
                                                                                       Bhutan, Saudi Arabia(220V),
                                                                                       Syria, Turkey, Algeria, Canary Is-
                                                                                       lands, Congo, Egypt, Gabon,
                                                                                       Morocco, Reunion, South Africa,
                                                                                       Indonesia, North Korea,
                                                                                       Philippines, Thailand, Vietnam,
                                                                                       New Caledonia, Tahiti
           DC9710 Battery Charger Set              DC1414 Battery Charger Set
                                         1                                       1      Dominica, U.K.
           193076-5                                193865-8
           DC9710 Battery Charger Set              DC1414 Battery Charger Set          Kuwait, Hong Kong, Malaysia,
                                         1                                       1     Singapore
           193085-4                                193865-8
           DC9710 Battery Charger Set              DC1414 Battery Charger Set
                                         1                                       1      Dominica, U.K.
           193182-6                                193865-8
           DC9710 Battery Charger Set              DC1414 Battery Charger Set          Kuwait, Hong Kong, Malaysia,
                                         1                                       1     Singapore
           193188-4                                193865-8
           DC9710 Battery Charger Set              DC1414 Battery Charger Set
                                         1                                       1      Australia, New Zealand
           193077-3                                193866-6
           DC9710 Battery Charger Set              DC1414 Battery Charger Set
                                         1                                       1      Australia, New Zealand
           193183-4                                193866-6
           DC9710 Battery Charger Set              DC1414 Battery Charger Set
                                         1                                       1      Brazil(110V)
           193081-2                                193869-0
           DC9710 Battery Charger Set              DC1414 Battery Charger Set
                                         1                                       1      Brazil(110V)
           193186-8                                193869-0
           DC9710 Battery Charger Set              DC1414 Battery Charger Set
                                         1                                       1      Korea
           193079-9                                193868-2
           DC9710 Battery Charger Set              DC1414 Battery Charger Set
                                         1                                       1      China
           193078-1                                193867-4
           DC9710 Battery Charger Set              DC1414 Battery Charger Set
                                         1                                       1      China
           193184-2                                193867-4
           DC9710 Battery Charger Set              DC1414 Battery Charger Set
                                         1                                       1     Argentina
           193082-0                                193873-9
           DC9710 Battery Charger Set              DC1414 Battery Charger Set
                                         1                                       1      Saudi Arabia(127V), Taiwan
           193080-4                                193877-1
           DC9710 Battery Charger Set              DC1414 Battery Charger Set
                                         1                                       1      Saudi Arabia(127V), Taiwan
           193185-0                                193877-1
                                                                                                       69669B
                                                                                                       (Page 3 of 4)

Item No.          Current part        Q'ty I/C           New part             Q'ty                Note
           DC1201 Fast Charger
                                                 DC1414 Battery Charger Set
           110-120V                    1                                       1      Panama
           192845-1                              193871-3
           DC1201 Fast Charger
                                                 DC1414 Battery Charger Set
           110-120V                    1                                       1      Saudi Arabia(127V)
           192845-1                              193877-1
           DC1201 Fast Charger                                                       Bolivia, Brazil(220V), Chile,
                                                 DC1414 Battery Charger Set
           220-230V                    1                                       1     Guyana, Paraguay, Peru, Uruguay,
           192838-8                              193864-0                            Austria, France, Germany, Italy,
                                                                                     Netherlands, Poland, Russia,
                                                                                     Spain, Sweden, Switzerland,
                                                                                     Bhutan, Saudi Arabia(220V),
                                                                                     Syria, Turkey, Algeria, Canary Is-
                                                                                     lands, Congo, Egypt, Gabon,
                                                                                     Morocco, Reunion, South Africa,
                                                                                     Indonesia, North Korea,
                                                                                     Philippines, Thailand, Vietnam,
                                                                                     New Caledonia, Tahiti
           DC1201 Fast Charger 230V              DC1414 Battery Charger Set          Bolivia, Brazil(220V), Chile,
                                       1                                       1     Guyana, Paraguay, Peru, Uruguay,
           192831-2                              193864-0
                                                                                     Austria, France, Germany, Italy,
                                                                                     Netherlands, Poland, Russia,
                                                                                     Spain, Sweden, Switzerland,
                                                                                     Bhutan, Saudi Arabia(220V),
                                                                                     Syria, Turkey, Algeria, Canary Is-
                                                                                     lands, Congo, Egypt, Gabon,
                                                                                     Morocco, Reunion, South Africa,
                                                                                     Indonesia, North Korea,
                                                                                     Philippines, Thailand, Vietnam,
                                                                                     New Caledonia, Tahiti
           DC1201 Fast Charger 220V              DC1414 Battery Charger Set
                                       1                                       1      Hong Kong
           192840-1                              193865-8
           DC1201 Fast Charger 220V              DC1414 Battery Charger Set
                                       1                                       1      Hong Kong
           192833-8                              193865-8
           DC1201 Fast Charger
                                                 DC1414 Battery Charger Set          Dominica, Kuwait, Malaysia,
           230-240V                    1                                       1
                                                 193865-8                            Singapore
           192842-7
           DC1201 Fast Charger 230V              DC1414 Battery Charger Set
                                       1                                       1      Singapore, Malaysia
           192835-4                              193865-8
           DC1201 Fast Charger 240V              DC1414 Battery Charger Set
                                       1                                       1      U.K., Kuwait
           192834-6                              193865-8
           DC1201 Fast Charger                   DC1414 Battery Charger Set
           230-240V                    1                                       1      Australia, New Zealand
                                                 193866-6
           192843-5
           DC1201 Fast Charger                   DC1414 Battery Charger Set
           230-240V                    1                                       1      Australia, New Zealand
                                                 193866-6
           192836-2
           DC1201 Fast Charger                   DC1414 Battery Charger Set
           110-120V                    1                                       1      Brazil(110V)
                                                 193869-0
           192846-9
           DC1201 Fast Charger 220V              DC1414 Battery Charger Set
                                       1                                       1      Korea
           192841-9                              193868-2
           DC1201 Fast Charger 220V              DC1414 Battery Charger Set
                                       1                                       1      China
           192839-6                              193867-4
           DC1201 Fast Charger 220V              DC1414 Battery Charger Set
                                       1                                       1      China
           192832-0                              193867-4
           DC1201 Battery Charger                DC1414 Battery Charger Set
                                       1                                       1     Argentina
           192921-1                              193873-9
                                                                                                           69669B
                                                                                                          (Page 4 of 4)

Item No.          Current part            Q'ty I/C            New part            Q'ty                Note
           DC9711 Battery Charger                    DC1414 Battery Charger Set          Bolivia, Brazil(220V), Chile,
                                            1                                      1
           193123-2                                  193864-0                            Guyana, Paraguay, Peru, Uruguay,
                                                                                         Austria, France, Germany, Italy,
                                                                                         Netherlands, Poland, Russia,
                                                                                         Spain, Sweden, Switzerland,
                                                                                         Bhutan, Saudi Arabia(220V),
                                                                                         Syria, Turkey, Algeria, Canary Is-
                                                                                         lands, Congo, Egypt, Gabon,
                                                                                         Morocco, Reunion, South Africa,
                                                                                         Indonesia, North Korea,
                                                                                         Philippines, Thailand, Vietnam,
                                                                                         New Caledonia, Tahiti
           DC9711 Battery Charger Set                DC1414 Battery Charger Set
                                            1                                      1     Dominica, U.K.
           193124-0                                  193865-8
           DC9711 Battery Charger Set                DC1414 Battery Charger Set
                                            1                                      1     Australia, New Zealand
           193125-8                                  193866-6
           DC9700 Battery Charger                    DC1414 Battery Charger Set
           220V                             1                                      1     Brazil(110V)
                                                     193869-0
           192926-1
           LG-124 Fast Charger                                                           Algeria, Italy, Netherlands,
                                                     LG-126 Battery Charger Set
           220-240V                         1                                      1     Spain, Germany, France,
           192716-2                                  193921-4
                                                                                         Reunion
           LG-124 Fast Charger
                                            1                                            U.K.
           192715-4
           LG-124 Fast Charger
                                            1                                            U.S.A.
           193167-2

Interchangeability mark ;
 The arrow      means that the new part can be substituted for the current.

Implementation
From around December 2003 production



◦ Jabse Service Manual Search 2022 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
