Image preview - the first page of the document
6960D-TE


>> Download 6960D-TE documenatation <<

Text preview - extract from the document
T     ECHNICAL INFORMATION                                                                                     New Tool

       For Models              6960D
       Description             Cordless Oil-Impulse Driver


CONCEPTION AND MAIN APPLICATIONS                                                                           50 mm
                                                                                                           (1-31/32")

  This new 12V impulse driver has an oil-impulse system                                       195 mm
  for reducing impact-noise drastically compared                                              (7-5/8")
  with the regular impact drivers.
  This new driver is suitable only for wood-screws.


                                                                                                           232 mm
                                                                                                                (9-1/8")

    Model         Battery(2.0Ah)      Fast charger       Plastic carrying case
    6960DA        Battery1222         No                 No
    6960DWA       Battery1222         DC1411             Yes




  Specifications
    Motor                                                         DC 12V magnet motor
    Battery                                                       Battery 1222(Ni-Cd, 12V, 2.0Ah)
    No load speed                                                 0-2500rpm
    Impacts per minute                                            0-1600
    Bit type                                                      Hex. shank bit Width across flats : 6.35mm(1/4")
    Max. fastening torque                                         300kgf.cm(260in.lbs)
    Capacities                     Wood screw
