Image preview - the first page of the document
69797-WW-1


>> Download 69797-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Battery Set
                                                                                                              69797


For Models            6017D, 6018D, 6019D, 6095D, 6096D
                      This Technical Information applies to machines manufactured at MME plant.
Country               European countries, Algeria, Reunion
Description           2.2 Ah Battery has been replaced by the higher capacity 2.6 Ah Battery set.


                            Current                       New                  Current                      New
 Name                      Battery 7033               Battery 7034            Battery 9033               Battery 9034
 Battery Capacity             2.2 Ah                     2.6 Ah                  2.2 Ah                    2.6 Ah

 Net weight               375 g (0.82 lbs)           390 g (0.86 lbs)        495 g (1.09 lbs)         520 g (1.14 lbs)
 Applicable Charger          DC1414                     DC1414                  DC1414                     DC1414
 Charging Time              50 minutes                 60 minutes              50 minutes                60 minutes

                                 139.5 mm (5-1/2")                                 182 mm (7-1/8")

 Shape                                                       48.5 mm                                               48.5 mm
                                                            (1-15/16")                                            (1-15/16")



Interchangeability(I/C)
 Item No.       Current part                 Q'ty I/C        New part                     Q'ty             Note
            Ni-MH Battery 7033                        Battery 7034 Set
                                              2   Yes                                       2    6017D, 6018D, 6019D
            192695-4                                  193888-6
            Ni-MH Battery 7033                        Battery 7034 Set
                                              1   Yes                                       1    6019D
            192695-4                                  193888-6
            Ni-MH Battery 9033                        Battery 9034 Set
    B02                                       2   Yes                                       2    6095D, 6096D
            192696-2                                  193889-4
            Ni-MH Battery 9033                        Battery 9034 Set
    B02                                       1   Yes                                       1    6095D, 6096D
            192696-2                                  193889-4
                                                      Battery 7034 Set
    F04                                                                                     1    6017D, 6018D, 6019D
                                                      193888-6
6095D:F02                                                 Battery 9034 Set
                                                                                            1    6095D, 6096D
6096D:F03                                                 193889-4


Implementation
From December 2003 production
