Image preview - the first page of the document
69719-WW-1


>> Download 69719-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Carbon Brush for Replacement
                                                                                                            69719


For Models            HM0860C, HM1100, HM1100C, HM1130, HM1130C, HM1140C, HR3000C, HR3550C,
                      HR4000C, HR4040C
Country               220V-240V countries
Description           Carbon brush for replacement has been changed to improve the durability.


         Current                        New                     Current                          New
                    Standard type                                Cost effective type for Asian countries




    Carbon Brush CB-304       Carbon Brush CB-323         Carbon Brush CB-304A       Carbon Brush CB-323A
         (191961-6)                (193922-2)                   (A-81670)                  (A-84034)



Interchangeability(I/C)
Item No.     Current part                   Q'ty I/C        New part                      Q'ty             Note
        Carbon Brush CB-304                           Carbon Brush CB-323
  091                                         1                                             1    HM0860C
        191961-6                                      193922-2
  See   Carbon Brush CB-304                           Carbon Brush CB-323                        The subject models
                                              1   Yes                                       1
 below. 191961-6                                      193922-2                                   except HM0860C
        Carbon Brush CB-304A                          Carbon Brush CB-323A
                                              1                                             1    HM0860C
        A-81670                                       A-84034
  See   Carbon Brush CB-304A                          Carbon Brush CB-323A                       The subject models
                                              1   Yes                                       1
 below. A-81670                                       A-84034                                    except HM0860C
Interchangeability mark ;
The arrow      means that the new part can be substituted for the current.

Item No. of Carbon Brush CB-304
  Model HM0860C HM1100 HM1100C HM1130 HM1130C HM1140C HR3000C HR3550C HR4000C HR4040C
Item No.    091      085      086 086   086     060     119     119     116     100

Item No. of Carbon Brush CB-323A
   Model HR3000C HR4040C
 Item No.     119       100

Note
Must use the new carbon brush Nos.193922-2 or A-84034 when replacing carbon brushes of HM0860C.

Implementation
CB-323: When the new parts get ready.
CB-323A: As soon as the stock of the current parts runs out.
