Image preview - the first page of the document
69721-WW-1


>> Download 69721-WW-1 documenatation <<

Text preview - extract from the document
TETHNICAL INFORMATION
Subject             Change of Brake Ring
                                                                                                      69721


For Models          BO5010, BO5011, BO5012, BO5020, BO5021
Country             All countries
Description         Brake ring has been changed to improve the durability as described below.




                                                          Current                               New
                                      Material Polyurethane Rubber NOK U801 Polyurethane Rubber NOK UF08
                                      Color            Yellowish white                   Black
                                      Part No.            416062-2                     421866-9
               Brake Ring


Interchangeability(I/C)

Item No.     Current part                Q'ty I/C         New part                    Q'ty        Note
   See Brake Ring                                  Brake Ring
                                           1   Yes                                      1
 below. 416062-2                                   421866-9
Item No. of Brake Ring
   Model BO5010 BO5011          BO5012      BO5020     BO5021
 Item No.     017      019       020         034        035

Implementation
To be implemented from December 2003 production
