Image preview - the first page of the document
69851-WW-1


>> Download 69851-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Addition of Vendor for Battery Charger DC1414 and DC1804
                                                                                                                 69851


For Models            DC1414, DC1804
Country               European countries, Australia, New Zealand

Description           In parallel with TAMURA-made DC1414 and DC1804, FRIWO-made DC1414 and DC1804
                      have become available. Instead of TAMURA-made battery charger, FRIWO's battery charger can
                      be stored in plastic carrying case. However FRIWO's component parts don't have interchangeability
                      with TAMURA's.

                      Therefore, see the list of "Interchangeability(I/C)" for the detail and choose either FRIWO's
                      component parts or TAMURA's by checking the following mark.


                                     Mark for distinction of FRIWO-made DC1804
                                                    in the name plate




Interchangeability(I/C)

Item No.         Current part               Q'ty I/C           New part                  Q'ty              Note

           DC1804 Battery Charger                      DC1804 Battery Charger                   For Australia,
    F03                                      1   Yes                                      1     New Zealand
           193829-2                                    193829-2
           DC1414 Battery Charger                      DC1414 Battery Charger                                     Part Nos.
    F02                                      1   Yes                                      1     For U.K.
           193865-8                                    193865-8                                                   remain
           DC1414 Battery Charger                      DC1414 Battery Charger                   For Australia,    the same.
    F03                                      1   Yes                                      1
           193866-6                                    193866-6                                 New Zealand
           DC1414 Battery Charger                      DC1414 Battery Charger                   For European
    F01                                      1   Yes                                      1
           193864-0                                    193864-0                                 countries except U.K.
           Charger Case Complete                       Charger Case Complete
    002                                      1    No                                      1
           153713-3                                    153768-8
                                                                                                For European countries
           Charger Case Cover                          Charger Case Cover                       (including U.K.),
    004                                      1    No                                      1
           418339-1                                    418346-4                                 Australia, New Zealand
           Battery Box                                 Battery Box
    007                                      1   Yes                                      1
           418392-7                                    418347-2
           Vinyl Cord 0.75-2-2.0                       Power Supply Cord                             For Australia,
    003                                      1   Yes                                      1
           667831-6                                    667832-4                                      New Zealand
           Vinyl Cord 0.75-2-2.0
                                                       Vinyl Cord 0.75-2-2.0
    003    BASEC                             1   Yes                                      1             For U.K.
           667986-7                                    667823-5
           Vinyl Cord 0.75-2-2.0                                                                 For European countries
                                                       Vinyl Cord 0.75-2-2.0
    003    CEE(13-52)                        1   Yes                                      1      except U.K.
           667985-9                                    667822-7

           Circuit Board                               Charging Circuit                         For European countries
    006                                      1    No                                      1     (including U.K.),
           631566-5                                    631568-1
                                                                                                Australia, New Zealand

Implementation
Since around November 2003 production
