Image preview - the first page of the document
69837-WW-1


>> Download 69837-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Ball Bearing
                                                                                                          69837


For Models           HP1620, HP1620F, HP1621, HP1621F
Country              All countries

Description          Ball bearing at commutator end of armature has been changed as illustrated below.
                     Ball bearing 627DDW at drive shaft of armature remains the same.

                                      Current                                   New
                                     Armature

                                           Commutator




                                Ball Bearing 627DDW                     Ball Bearing 627LB
                                      (210023-2)                             (211028-5)


Interchangeability(I/C)

Item No.          Current part                  Q'ty I/C           New part              Q'ty            Note
           Ball Bearing 627DDW                             Ball Bearing 627LB
    021                                          1                                         1
           210023-2                                        211028-5
Interchangeability mark ;
The arrow      means that the new part can be substituted for the current.


Implementation
Since October 2003 production
